Lenze EVS9332xP - Manual (Page 295)

Configuration
Basic configurations
8
8.5
l
8.5−29 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0655 CONV5−
NUMERATOR
1 −32767 {1} 32767 CONV5
Numerator
See system
manual
(extension)
C0656 CONV5−DENO
MINATOR
1 1 {1} 32767 CONV5
Denominator
C0657
s
CONV5−IN 1000 FIXED0% ® Selection list 1 CONV5
Configuration − analog input
signal
C0658 CONV5−IN g −199.99 {0.01 %} 199.99 CONV5
Display of analog input signal
C0661
s
ABS1−IN 1000 FIXED0% ® Selection list 1 ABS1
Configuration − analog input
signal
l Input for absolute value
generators
See system
manual
(extension)
C0662 ABS1−IN g −199.99 {0.01 %} 199.99 ABS1
Display of analog input signal
C0671 RFG1−TIR 0.000 0.000 {0.01 s} 999.900 RFG1
Acceleration time T
ir
See system
manual
(extension)
C0672 RFG1−TIF 0.000 0.000 {0.01 s} 999.900 RFG1
Deceleration time T
if
C0673
s
RFG1−IN 1000 FIXED0% ® Selection list 1 RFG1
Configuration − analog input
signal
C0674
s
RFG1−SET 1000 FIXED0% ® Selection list 1 RFG1
Configuration − analog input
signal
C0675
s
RFG1−LOAD 1000 FIXED0 ® selection list 2 RFG1
Configuraton of digital input
signal
C0676
g
−199.99 {0.01 %} 199.99 RFG1
Display of analog input signals
1 RFG1−IN
2 RFG1−SET
C0677 RFG1−LOAD g RFG1
Display of digital input signal
C0680 CMP1−
FUNCTION
6 1
2
3
4
5
6 IN1 = IN 2
IN 1 > IN2
IN 1 < IN2
|IN1| = |IN2|
|IN1| > |IN2|
|IN1| < |IN2| CMP1
Function selection
l Comparison of inputs IN1
and IN2
See system
manual
(extension)
C0681 CMP1−
HYSTERESIS
1.00 0.00 {0.01 %} 100.00 CMP1
Hysteresis
C0682 CMP1−
WINDOW
1.00 0.00 {0.01 %} 100.00 CMP1
Window
C0683
s
® Selection list 1 CMP1
Configuration of analog input
signals
1 CMP1−IN1 5001 MCTRL−NACT
2 CMP1−IN2 19500 FCODE−17
C0684 g −199.99 {0.01 %} 199.99 CMP1
Display of analog input signals
1 (C0683/1)
2 (C0683/1)
