Preface and general information
How to use this System Manual
Information provided by the System Manual
1
1.1
1.1.1
l
1.1−1 EDSVS9332P EN 5.0−07/2013
1.1 How to use this System Manual
1.1.1 Information provided by the System Manual
This System Manual addresses to all persons who dimension, install,
commission, and set 9300 servo position controllers.
Together with the System Manual (extension), document number
EDSVS9332P−EXT, and the catalogue, it provides the basis for project
planning for the mechanical engineer and the plant constructor.
The System Manual provides the basis for the description of the 9300 servo
position controller. Together with the System Manual (extension),
document number EDSVS9332P−EXT, a complete System Manual is
available:
ƒ The features and functions are described in detail.
ƒ The parameterisation for typical applications is explained by the use of
examples.
ƒ In case of doubt, the Mounting Instructions supplied with the 9300
servo position controller are always valid.
Contents of System Manual Contents of the System Manual (extension)
1 Preface 1 Preface
2 Safety −
3 Technical data −
4 Mounting the standard device −
5 Wiring the standard device −
6 Commissioning −
7 Parameter setting −
8 Configuration 2 Configuration
8.1 Monitoring 2.1 Configuration with Global Drive Control
8.2 Monitoring functions 2.2 Basic configuration
8.3 Code table 2.3 Operating modes
8.4 Selection lists
8.5 Table of attributes
− 3 Function library
− 4 Application examples
9 Troubleshooting and fault
elimination −
10 DC−bus operation −
11 Safety engineering −
12 Accessories −
13 Appendix 5 Appendix
