Configuration
Basic configurations
8
8.5
l
8.5−21 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0464 CUSTOMER I/F g 0
1 Original
Changed Customer interface
Status of selected basic
configuration
l Reassignment of terminals
in a basic configuration in
C0005 does not change
C0005 and sets C0464 = 1
l Adding or removing function
blocks or changing the signal
flow among the function
blocks in a basic
configuration of C0005 sets
C0005 = 0 and C0464= 1
C0465
s
FB LIST ® ® selection list 5 FB processing table
Contained in the program of
signal processing (sequence in
which the function blocks are
processed)
à Depending on C0005.
Changing C0005 loads
assigned processing list
– Lenze setting:
C0005 = 20000
l After changing the signal
flow, the processing table
must be adapted. Otherwise
the controller uses the
wrong signals!
l The function blocks DIGIN,
DIGOUT, AIF−IN, CAN−IN, and
MCTRL are always processed
and do not have to be
entered in the list
See system
manual
(extension)
1 0
2 0
... ...
20 30000
... 0
25 5700
26 10600
... 0
30 70
... ...
33 75
... ...
36 250
... ...
39 20000
... ...
50 0
C0466 CPU T REMAIN
g
Remaining process time
For processing function blocks
C0469
s
KEY STOP
FUNCTION 2 0
1
2 Deactivated
Set CINH, controller inhibit
Set QSP, quick stop Keypad
Set function of the STOP key on
the keypad
C0470 0 {1} 255 FCODE
Freely configurable code for
digital signals
l The data words C0470 and
C0471 are in parallel and are
identical
See system
manual
(extension)
0 FCODE 8BIT
DIGITAL
0
1 FCODE BIT 0−7 0
2 FCODE BIT8−15 0
3 FCODE
BIT16−23
0
4 FCODE
BIT24−31
0
C0471 FCODE 32 BIT 0 0 {1} 4294967296 FCODE 32 bits digital
Freely configurable code for
digital signals
l The data words C0470 and
C0471 are in parallel and are
identical
See system
manual
(extension)
