Configuration
Basic configurations
8
8.5
l
8.5−22 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0472 FCODE
ANALOG
−199.99 {0.01 %} 199.99 FCODE
Freely configurable code for
relative analog signals
See system
manual
(extension)
1 0.00
2 0.00
3 100.00
... ...
6 100.00
... ...
20 0.00
C0473 FCODE ABS −32767 {1} 32767 FCODE
Freely configurable code for
absolute analog signals
See system
manual
(extension)
1 1
2 1
3 0
... ...
10 0
C0474 FCODE PH −2147483648 {1} 2147483647 FCODE
Freely configurable code for
angle singals
l 1 rev. = 65536 inc
See system
manual
(extension)
1 0
... ...
5 0
C0475 FCODE DF −16000 {1 rpm} 16000 FCODE
Freely configurable code for
angular difference singals
l 1 rev. = 65536 inc
See system
manual
(extension)
1 0
2 0
C0490
s
FEEDBACK POS 0 Position feedback system
Feedback system for the
position controller
0 Resolver at X7 The feedback system can be
combined with the settings
C0495 = 0, 1, 2, 3, 4
1 Encoder TTL at X8 The selection also sets C0495 to
the same value
2 Encoder sin an X8
3 Absolute value encoder ST at X8
4 Absolute value encoder MT at X8
C0495
s
FEEDBACK N 0 Speed feedback system
Feedback system for the speed
controller
0 Resolver at X7 The feedback system can be
combined with the settings
C0490 = 0, 1, 2, 3, 4
l C0490 = 0 sets the rotor
displacement angle in C0058
to −90°
1 Encoder TTL at X8 The selection also sets C0490 to
the same value
2 Encoder sin an X8
3 Absolute value encoder ST at X8
4 Absolute value encoder MT at X8
C0497 NACT−FILTER 2.0 0.0 {0.1 ms} 50.0 n
act filter time constant
Time constant for actual speed
value
C0497 = 0 ms: Switched off
