Configuration
Basic configurations
8
8.5
l
8.5−24 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0528
g
−2 . 10 9 {1} 2 . 10 9 DFSET See system
manual
(extension)
1 0−PULSE A Angular difference between 2
index pulses
2 OFFSET Offset from
C0523 × C0529 + C0252
C0529 MULTIP
OFFSET
1 −20000 {1} 20000 DFSET
Offset multiplier
C0530 DF
EVALUATION
0 0 With gearbox factor DFSET
Evaluation of the digital
frequency
1 Without gearbox factor
C0531 ACT 0 DIV 1 1 {1} 16384 DFSET
Divisor for actual zero pulse
C0532 0−PULSE/TP 1 1
2 0−pulse
Touch probe DFSET
Selection of zero pulse or touch
probe
C0533 VP DENOM 1 1 {1} 32767 DFSET Vp denominator
Gain factor denominator
C0534 SYNC MODE 0 0
1
2
10
11
12
13 Inactive
Continuous
Continuously switchable
Once, fast way
Once, + direction
Once, − direction
Once, 2 × zero pulse DFSET
Mode for synchronising the
zero pulse and/or touch probe
C0535 SET 0 DIV 1 1 {1} 16384 DFSET
Set zero pulse scaler
C0536 g −32767 {1} 32767 DFSET
Display of analog input signals
See system
manual
(extension)
1 DFSET−VP−DIV
2 DFSET−RAT−DIV
3 DFSET−A−TRIM
C0537 DFSET−N−TRIM g −199.99 {0.01 %} 199.99 DFSET
Display of analog input signal
C0538
g DFSET
Display of digital input signals
1 DFSET−0−PULSE
2 DFSET−RESET
3 DFSET−SET
C0539 DFSET−IN g −32767 {1 rpm} 32767 DFSET
Display of input signal
C0540 DFOUT−
FUNCTION
2 0
1
2
3
4
5 Analog input
Phase difference input
Resolver simulation + index pulse
Resolver simulation without index
pulse
X10 = X9
X10 = X8 DFOUT
Encoder output function
l X9 is inhibited if 0, 1, 2 or 3
has been selected
l The input signals are
buffered
See system
manual
(extension)
C0541
s
DFOUT−AN−IN 1000 FIXED0% ® Selection list 1 DFOUT
Configuration − analog input
signal
See system
manual
(extension)
C0542
s
DFOUT−DF−IN 5000 MCTRL−PHI−ACT ® Selection list 4 DFOUT
Digital frequency signal
configuration
C0544
s
DFOUT−SYN−
RDY 1000 FIXED0 ® selection list 2 DFOUT
Configuration of
synchronisation signal for the
zero pulse
