Configuration
Selection lists
Selection list 1: Analog output signals
8
8.6
8.6.1
l
8.6−1 EDSVS9332P EN 5.0−07/2013
8.6 Selection lists
8.6.1 Selection list 1: Analog output signals
Parameter Analog output signal ( H)
000050 AIN1−OUT
000055 AIN2−OUT
000100 DFSET−NOUT
001000 FIXED0%
001006 FIXED100%
001007 FIXED−100%
005000 MCTRL−NSET2
005001 MCTRL−NACT
005002 MCTRL−MSET2
005003 MCTRL−MACT
005004 MCTRL−IACT
005005 MCTRL−DCVOLT
005009 MCTRL−PHI−ANA
005050 NSET−NOUT
005051 NSET−RFG−I
005100 MPOT1−OUT
005550 ADD1−OUT
005600 RFG1−OUT
005650 ASW1−OUT
005655 ASW2−OUT
005700 ANEG1−OUT
005705 ANEG2−OUT
006200 CONV1−OUT
006205 CONV2−OUT
006210 CONV3−OUT
006215 CONV4−OUT
006230 CONVPHA1−OUT
006232 CONVPHA2−OUT
006234 CONVPHA3−OUT
006300 S&H1−OUT
006350 CURVE1−OUT
006400 FCNT1−OUT
006405 FCNT2−OUT
006410 FCNT3−OUT
006550 TEACH1−CNT
006600 SYNC1−OUT3
007200 CONVDA1−OUT
007205 CONVDA2−OUT
007210 CONVDA3−OUT
010000 BRK1−M−SET
015028 MCTRL−Utilization
015030 MCTRL−LOAD−I2Xt
Parameter Analog output signal ( H)
019500 FCODE−17
019502 FCODE−26/1
019503 FCODE−26/2
019504 FCODE−27/1
019505 FCODE−27/2
019506 FCODE−32
019507 FCODE−37
019510 FCODE−108/1
019511 FCODE−108/2
019512 FCODE−109/1
019513 FCODE−109/2
019515 FCODE−141
019517 FCODE−1211
019521 FCODE−472/1
019522 FCODE−472/2
019523 FCODE−472/3
019524 FCODE−472/4
019525 FCODE−472/5
019526 FCODE−472/6
019527 FCODE−472/7
019528 FCODE−472/8
019529 FCODE−472/9
019530 FCODE−472/10
019531 FCODE−472/11
019532 FCODE−472/12
019533 FCODE−472/13
019534 FCODE−472/14
019535 FCODE−472/15
019536 FCODE−472/16
019537 FCODE−472/17
019538 FCODE−472/18
019539 FCODE−472/19
019540 FCODE−472/20
019551 FCODE−473/1
019552 FCODE−473/2
019553 FCODE−473/3
019554 FCODE−473/4
019555 FCODE−473/5
019556 FCODE−473/6
019557 FCODE−473/7
019558 FCODE−473/8
019559 FCODE−473/9
