Configuration
Basic configurations
8
8.5
l
8.5−77 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1650
s
SP2−RESET 1000 FIXED0 ® selection list 2 SP2
Configuraton of digital input
signal
C1651 0
1
...
104 Real zero
VTPOS−No 001
...
VTPOS−No 104 SP2
1 SP2−VALUE 1−1 1 Switching point output
SP2−STAT1
2 SP2−VALUE 1−2 1
3 SP2−VALUE 2−1 1 Switching point output
SP2−STAT2
4 SP2−VALUE 2−2 1
5 SP2−VALUE 3−1 1 Switching point output
SP2−STAT3
6 SP2−VALUE 3−2 1
7 SP2−VALUE 4−1 1 Switching point output
SP2−STAT4
8 SP2−VALUE 4−2 1
9 SP2−VALUE 5−1 1 Switching point output
SP2−STAT5
10 SP2−VALUE 5−2 1
11 SP2−VALUE 6−1 1 Switching point output
SP2−STAT6
12 SP2−VALUE 6−2 1
13 SP2−VALUE 7−1 1 Switching point output
SP2−STAT8
14 SP2−VALUE 7−2 1
15 SP2−VALUE 8−1 1 Switching point output
SP2−STAT8
16 SP2−VALUE 8−2 1
C1652
s
SP2−L−IN 1000 FIXED0INC ® Selection list 3 SP2
Configuration of input signal
C1653 SP2−RESET g 0 1 SP2
Display of digital input signal
C1654 SP2−L−IN g −1073741824 {1 inc} 1073741823 SP2
Display of input signal
C1655 SP2−MODE 0 0 Starting point and final point SP2
Setting of the switching points
1 Centre with switch range
C1657 −30000 {1 ms} 30000 SP2
Dead time
1 DEAD TIME 0
... ... 0
4 DEAD TIME 0
C1658 HYSTERESIS 0 −32767 {1 inc} 32767 SP2
Hysteresis
C1659 FILTER 1 0
1
2
4
8
16 Filter off
Filter 1 ms
Filter 2 ms
Filter 4 ms
Filter 8 ms
Filter 16 ms SP2
Filters
