Configuration
Basic configurations
8
8.5
l
8.5−80 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1681 CMPPH3−
HYSTERESIS
50 0 {1 inc} 1073741824 CMPPH3
Hysteresis to compensate an
oscillating output signal due to
unstable input signals
See system
manual
(extension)
C1682 CMPPH3−
WINDOW
0 0 {1 inc} 1073741824 CMPPH3
Window within which the
phase signals comply with each
other
C1683
s
® Selection list 3 CMPPH3
Configuration of input signals
1 CMPPH3−IN1 1000 FIXED0INC
2 CMPPH3−IN2 1000 FIXED0INC
C1684 g −2147483647 {1 inc} 2147483647 CMPPH3
Display of input signals
1 CMPPH3−IN1
2 CMPPH3−IN2
C1690
s
® Selection list 1 DISA
Configuration of analog input
signals
See system
manual
(extension)
1 DISA−IN1 1000 FIXED0%
... ... ... ...
10 DISA−IN10 1000 FIXED0%
C1691 g −199.99 {0.01 %} 199.99 DISA
Display of the input signals in
the analog format
1 DISA−IN (%)1
... ...
10 DISA−IN (%)10
C1692 g −32768 {1} 32768 DISA
Display of the input signals in
the decimal format
1 DISA−IN
(VALUE)1
... ...
10 DISA−IN
(VALUE)10
C1693 g 0 {1 hex} 65536 DISA
Display of the input signals in
the hexadecimal format
1 DISA−IN (HEX)1
... ...
10 DISA−IN
(HEX)10
C1695
s
® Selection list 3 DISPH
Configuration of input signals
See system
manual
(extension)
1 DISPH−IN1 1000 FIXED0INC
... ... ... FIXED0INC
10 DISPH−IN10 1000 FIXED0INC
C1696 g −2147483647 {1 inc} 2147483647 DISPH
Display of input signals
1 DISPH−IN1
... ...
10 DISPH−IN10
