Lenze EVS9332xP - Manual (Page 338)

Configuration
Basic configurations
8
8.5
l
8.5−72 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1546
s
FEVAN6−IN 1000 FIXED0% ® Selection list 1 FEVAN6
Configuration − analog input
signal
See system
manual
(extension)
C1547
s
® selection list 2 FEVAN6
Configuration of digital input
signals
1 FEVAN6−LOAD 1000 FIXED0
2 FEVAN6−
BUSY−IN
1000 FIXED0
3 FEVAN6−FAIL−I
N
1000 FIXED0
C1548 FEVAN6−IN g −32768 {1} 32767 FEVAN6
Display of analog input signal
C1549 g FEVAN6
Configuration of digital input
signals
1 FEVAN6−LOAD
2 FEVAN6−
BUSY−IN
3 FEVAN6−FAIL−I
N
C1550 ARITPH4
FUNCTION
1 0
1
2
3
13
14
15
21
22 OUT = IN1
OUT = IN1 + IN2
OUT = IN1 − IN2
OUT = IN1 × IN2 / 2
30
OUT = IN1 × IN2
OUT = IN1 / IN2
OUT = IN1 % IN2
OUT = IN1 + IN2 (no limit)
OUT = IN1 − IN2 (no limit)
ARITPH4
Arithmetic function selection See system
manual
(extension)
C1551
s
® Selection list 3 ARITPH4
Configuration of input signals
1 ARITPH4−IN1 1000 FIXED0INC
2 ARITPH4−IN2 1000 FIXED0INC
C1552 g −2147483647 {1} 2147483647 ARITPH4
Display of input signals
1 ARITPH4−IN1
2 ARITPH4−IN2
C1555 ARITPH5
FUNCTION
1 0
1
2
3
13
14
15
21
22 OUT = IN1
OUT = IN1 + IN2
OUT = IN1 − IN2
OUT = IN1 × IN2 / 2
30
OUT = IN1 × IN2
OUT = IN1 / IN2
OUT = IN1 % IN2
OUT = IN1 + IN2 (no limit)
OUT = IN1 − IN2 (no limit)
ARITPH5
Arithmetic function selection See system
manual
(extension)
C1556
s
® Selection list 3 ARITPH5
Configuration of input signals
1 ARITPH5−IN1 1000 FIXED0INC
2 ARITPH5−IN2 1000 FIXED0INC
C1557 g −2147483647 {1} 2147483647 ARITPH5
Display of input signals
1 ARITPH5−IN1
2 ARITPH5−IN2
