Configuration
Basic configurations
8
8.5
l
8.5−74 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1573
s
® selection list 2 CONVDA2
Configuration of digital input
signals
See system
manual
(extension)
1 CONVDA2−B0 1000 FIXED0
2 CONVDA2−B1 1000 FIXED0
3 CONVDA2−B2 1000 FIXED0
4 CONVDA2−B3 1000 FIXED0
5 CONVDA2−B4 1000 FIXED0
6 CONVDA2−B5 1000 FIXED0
7 CONVDA2−B6 1000 FIXED0
8 CONVDA2−B7 1000 FIXED0
9 CONVDA2−B8 1000 FIXED0
10 CONVDA2−B9 1000 FIXED0
11 CONVDA2−B10 1000 FIXED0
12 CONVDA2−B11 1000 FIXED0
13 CONVDA2−B12 1000 FIXED0
14 CONVDA2−B13 1000 FIXED0
15 CONVDA2−B14 1000 FIXED0
16 CONVDA2−
SIGN
1000 FIXED0
C1574 RESULT g 0 {1 hex} 65536 CONVDA2
Display of the result
C1576
s
® selection list 2 CONVDA3
Configuration of digital input
signals
See system
manual
(extension)
1 CONVDA3−B0 1000 FIXED0
2 CONVDA3−B1 1000 FIXED0
3 CONVDA3−B2 1000 FIXED0
4 CONVDA3−B3 1000 FIXED0
5 CONVDA3−B4 1000 FIXED0
6 CONVDA3−B5 1000 FIXED0
7 CONVDA3−B6 1000 FIXED0
8 CONVDA3−B7 1000 FIXED0
9 CONVDA3−B8 1000 FIXED0
10 CONVDA3−B9 1000 FIXED0
11 CONVDA3−B10 1000 FIXED0
12 CONVDA3−B11 1000 FIXED0
13 CONVDA3−B12 1000 FIXED0
14 CONVDA3−B13 1000 FIXED0
15 CONVDA3−B14 1000 FIXED0
16 CONVDA3−
SIGN
1000 FIXED0
C1577 RESULT g 0 {1 hex} 65536 CONVDA3
Display of the result
C1580
s
CONVAD1−IN 1000 FIXED0% ® Selection list 1 CONVAD1
Configuration − analog input
signal
See system
manual
(extension)
C1581 CONVAD1−IN g −32768 {1} 32767 CONVAD1
Display of analog input signal
