Configuration
Basic configurations
8
8.5
l
8.5−14 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0252 ANGLE OFFSET 0 −245760000 {1 inc} 245760000 DFSET
Anglular offset, fixed angular
offset for digital frequency
configurations
l 1 rev = 65536 inc
See system
manual
(extension)
C0253 ANGLE N−TRIM ® −32767 {1 inc} 32767 DFSET
Speed−dependent phase
trimming
à Depending on C0005,
C0025, C0490
l Change of C0005, C0025, or
C0490 resets C0253 to the
Lenze settingassigned
l 1 rev. = 65536 inc
l C0253 is reached at 15000
rpm
See system
manual
(extension)
C0254 VP ANGLE CTRL 0.4000 0.0000 {0.0001} 3.9999 MCTRL
Gain V
p
of the angle controller
See system
manual
(extension)
C0255 THRESHOLD
P03
327680 10 {1 inc} 1800000000 Following error limit P03
l 1 rev. = 65536 inc
l Following error > C0255
triggers fault "P03"
C0260 MPOT1 HIGH 100.00 −199.99 {0.01 %} 199.99 MPOT1
Upper limit
l Condition: C0260 > C0261
See system
manual
(extension)
C0261 MPOT1 LOW −100.00 −199.99 {0.01 %} 199.99 MPOT1
Lower limit
l Condition: C0261 < C0260
See system
manual
(extension)
C0262 MPOT1 TIR 10.0 0.1 {0.1 s} 6000.0 MPOT1
Acceleration time (rel. to
change 0 ... 100 %)
See system
manual
(extension)
C0263 MPOT1 TIF 10.0 0.1 {0.1 s} 6000.0 MPOT1
Deceleration time (rel. to
change 0 ... 100 %)
See system
manual
(extension)
C0264 MPOT1
ON/OFF
0 0
1
2
3
4
5 No change
Deceleration with T
if
to 0%
Deceleration with T
if
to C0261
Skip with T
if
= 0 to 0%
Skip with T
if
= 0 to C0261
Acceleration with T
ir
to C0260
MPOT1
Executable functions if motor
potentiometer is deactivated
via input MPOT1−INACTIVE See system
manual
(extension)
C0265 MPOT1 INIT 0 0
1
2 Value during mains failure
Lower limit value from C0261
0 % MPOT1
Initialisation
Value which is accepted at
mains switching and activated
motor potentiometer See system
manual
(extension)
C0267
s
® selection list 2 MPOT1
Configuration of digital input
signals
See system
manual
(extension)
1 MPOT1−UP 1000 FIXED0
2 MPOT1−DOWN 1000 FIXED0
C0268
s
MPOT1−INACT 1000 FIXED0 ® selection list 2 MPOT1
Configuraton of digital input
signal
See system
manual
(extension)
C0269 g MPOT1 See system
manual
(extension)
1 MPOT1−UP
2 MPOT1−DOWN
3 MPOT1−INACT
