Configuration
Overview of monitoring functions
8
8.3
l
8.31
EDSVS9332P
EN 5.0−07/2013
8.3 Overview of monitoring functions
The responses of monitoring functions can be partly parameterised via codes ˘ in GDC in the parameter
menu under Monitoring ˘.
Monitoring Possible fault responses
l Lenze setting
ü Can be set
Fault message Description Source Code TRIP Message Warning Fail−QSP Off
x071 CCR System fault Internal l
x091 EEr External monitoring (triggered via DCTRL) FWM C0581 l ь ь ь
Voltage supply
1020 OU Overvoltage in the DC bus (C0173) MCTRL l
1030 LU Undervoltage in the DC bus (C0173) MCTRL l
0107 H07 Internal fault (power section) Internal l
Communication
x061 CE0 Communication error on the automation interface (AIF) AIF C0126 ь ь l
x062 CE1 Communication error on the CAN1_IN process data input object
(monitoring time adjustable via C0357/1) CAN1_IN C0591 ь ь l
x063 CE2 Communication error on the CAN2_IN process data input object
(monitoring time adjustable via C0357/2) CAN2_IN C0592 ь ь l
x064 CE3 Communication error on the CAN3_IN process data input object
(monitoring time adjustable via C0357/3) CAN3_IN C0593 ь ь l
x065 CE4 BUS−OFF state of the system bus (CAN)
(too many faulty telegrams) CAN C0595 ь ь l
x166 P16 Faulty transmission of the sync telegram (system bus CAN) Internal C1290/1 ь ь l ü
Temperatures / sensors
x050 OH Heatsink temperature > 85° C MCTRL l
x053 OH3 Motor temperature > 150° C MCTRL C0583 l ь ь
x054 OH4 Heatsink temperature > C0122 MCTRL C0582 l ü
x057 OH7 Motor temperature > C0121 MCTRL C0584 l ü
x058 OH8 Motor temperature via inputs T1 and T2 is too high.
Caution: At "warning" (C0585 = 2) or "off" (C0585 = 3), the
drive can be destroyed if the fault is not eliminated in time! MCTRL C0585 ь ь l
x086 Sd6 Thermal sensor error on the motor (X7 or X8) MCTRL C0594 ь ь l
x110 H10 Thermal sensor error at the heatsink FWM C0588 l 1) 1)
x111 H11 Thermal sensor error in the device interior FWM C0588 l 1) 1)
Motor / feedback system
0011 OC1 Short circuit of motor cable MCTRL l
0012 OC2 Motor cable earth fault MCTRL l
