Wiring of the standard device
Control terminals
Technical data
5
5.8
5.8.7
l
5.8−11 EDSVS9332P EN 5.0−07/2013
Analog inputs, analog outputs
Terminal Description Field Values
X6/1
X6/2 Analog input 1 Voltage range
Level −10 V ... +10 V
Resolution 5 mV (11 Bit + sign)
Current range
Level −20 mA ... +20 mA
Resolution 20 m A (10 Bit + sign)
X6/3
X6/4 Analog input 2 Voltage range
Level −10 V ... +10 V
Resolution 5 mV (11 Bit + sign)
X6/62 Analog output 1 Level −10 V ... +10 V
Load capacity Maximum 2 mA
Resolution 20 mV (9 bits + sign)
Cycle time 1 ms (smoothing time t = 2 ms)
X6/63 Analog output 2 Level −10 V ... +10 V
Load capacity Maximum 2 mA
Resolution 20 mV (9 bits + sign)
Cycle time 1 ms (smoothing time t = 2 ms)
X6/7 GND1 Reference potential for analog signals
Isolated to X5/39 (GND2)
