Configuration
Basic configurations
8
8.5
l
8.5−66 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1361
g POS
Display of digital input signals See system
manual
(extension)
1 POS−PRG−STAR
T
2 POS−PRG−STOP
3 POS−PRG−
RESET
4 POS−LIM−NEG
5 POS−LIM−POS
6 POS−MANUAL
7 POS−MANU−NE
G
8 POS−MANU−PO
S
9 POS−MANU−RE
F
10 POS−REF−MARK
11 POS−TP1−
ENABL−TP1
12 POS−TP2−
ENABL−TP2
13 POS−TP3−
ENABL−TP3
14 POS−TP4−
ENABL−TP4
15 POS−PS−CANCE
L
16 POS−STDBY−ST
P
17 POS−S−RAMPS
18 POS−PARAM−R
D
19 POS−LOOP−INH
20 POS−PSET−SWT
21 POS−ABS−SET
22 POS−WAITSTAT
E
C1362
s
® Selection list 1 POS
Configuration of analog input
signals
See system
manual
(extension)
1 POS−START−PS 19517 FCODE−1211
2 POS−V−
OVERRID
1006 FIXED100%
3 POS−A−
OVERRID
1006 FIXED100%
4 POS−N−IN 1000 FIXED0%
5 POS−NOUT−GAI
N
1006 FIXED100%
6 POS−M−IN 1000 FIXED0%
7 POS−MOUT−GA
IN
1000 FIXED0%
8 POS−JERK−RED 1006 FIXED100%
