Configuration
Basic configurations
8.5
l
8.5−57
EDSVS9332P EN 5.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C1223
s
POS. LIMIT+
16000.
0000
0
{0.0001 units}
214000.
0000
POS
Position limit positive
See system
manual
(extension)
C1224
s
POS. LIMIT−
−16000.
0000
−214000
.0000
{0.0001 units}
0 POS
Position limit negative
C1225 HOME OFFSET
0
−214000
.0000
{0.0001 units}
214000.
0000
POS
Homing measure offset
C1227 HOME
POSITION
0
−214000
.0000
{0.0001 units}
214000.
0000
POS
Home position
See system
manual
(extension)
C1240 V−MAX
50.000
0
0.0001
{0.0001units/s}
214000.
0000
POS
Max. speed v
max
See system
manual
(extension)
C1241 V−HOMING 2
2.00
0.01
{0.01 %vmax}
100.00 POS
Second homing speed
C1242 V−HOMING
5.00
0.01
{0.01 %vmax}
100.00 POS
Homing speed
C1243 V−MANUAL
5.00
0.01
{0.01 %vmax}
100.00 POS
Manual speed
C1245
g
−199.99
{0.01 %vmax}
199.99 POS
Display of speeds
See system
manual
(extension)
1 POS−VSET
Actual speed setpoint
2 POS−VTRAV
Traversing speed of current
program set
3 POS−VFINAL
Final speed of current program
set
C1250 A−MAX
100.00
00
0.0001
{0.0001 units/s
2
}
214000.
0000
POS
Max. acceleration/deceleration
a
max
C1251 A−HOMING
10.00
0.01
{0.01 %amax}
100.00 Acceleration/deceleration of
homing
^ 6.13−1
See system
manual
(extension)
C1252 A−MANUAL
10.00
0.01
{0.01 %amax}
100.00 Acceleration/deceleration of
manual jog
See system
manual
(extension)
C1253 A−CANCEL
100.00 0.01
{0.01 %amax}
100.00 Deceleration PS−CANCEL
Deceleration of the drive until
standstill when the PS is
aborted
See system
manual
(extension)
C1255
g
−199.99
{0.01 %amax}
199.99 POS
See system
manual
(extension)
1 POS−ASET
Actual
acceleration/deceleration
2 POS−ACC
Acceleration of current PS
3 POS−DCC
Deceleration of current PS
C1256 S−RMP: JERK
1
0.064
{0.001
s}
10 POS
S−ramp, max. jerk
See system
manual
(extension)
C1257 S−RMP: FILTER
10
0
{1 rpm}
1000 S−ramp
PARAM−RD filter
C1259
0
1
Linear ramp
S−ramp
POS
Mode of the deceleration ramp
See system
manual
(extension)
1 MODE MAN
RAMP
0
Deceleration of manual jog
2 MODE STP
RAMP
0
Deceleration program stop
3 MODE CANCEL
0
Deceleration of PS−CANCEL
