Configuration
Basic configurations
8.5
l
8.5−70
EDSVS9332P EN 5.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C1516
s
FEVAN3−IN
1000
FIXED0%
® Selection list 1 FEVAN3
Configuration − analog input
signal
See system
manual
(extension)
C1517
s
® selection list 2 FEVAN3
Configuration of digital input
signals
1 FEVAN3−LOAD
1000
FIXED0
2 FEVAN3−BUSY−
IN
1000
FIXED0
3 FEVAN3−FAIL−I
N
1000
FIXED0
C1518 FEVAN3−IN
g
−32768
{1}
32767 FEVAN3
Display of analog input signal
C1519
g
FEVAN3
Display of digital input signals
1 FEVAN3−LOAD
2 FEVAN3−BUSY−
IN
3 FEVAN3−FAIL−I
N
C1520 OUTPUT
SIGNAL
−2147483648
{1}
2147483647 FEVAN4
Signal output
See system
manual
(extension)
C1521 FEVAN4 CODE
141
2
{1}
2000 FEVAN4
Target code of FEVAN4
C1522 SUBCODE
0
0
{1}
255 FEVAN4
Target subcode FEVAN4
C1523 FEVAN4
NUMERATOR
1.0000 0.0001
{0.0001}
100000.0000 FEVAN4
Numerator
C1524 FEVAN4
DENOMINATO
R
0.0001 0.0001
{0.0001}
100000.0000 FEVAN4
Denominator
C1525 FEVAN4
OFFSET
0
0
1000000000 FEVAN4
Offset
C1526
s
FEVAN4−IN
1000
FIXED0%
® Selection list 1 FEVAN4
Configuration − analog input
signal
See system
manual
(extension)
C1527
s
® selection list 2 FEVAN4
Configuration of digital input
signals
1 FEVAN4−LOAD
1000
FIXED0
2 FEVAN4−BUSY−
IN
1000
FIXED0
3 FEVAN4−FAIL−I
N
1000
FIXED0
C1528 FEVAN4−IN
g
−32768
{1}
32767 FEVAN4
Display of analog input signal
C1529
g
FEVAN4
Display of digital input signals
1 FEVAN4−LOAD
2 FEVAN4−BUSY−
IN
3 FEVAN4−FAIL−I
N
