Configuration
Basic configurations
8
8.5
l
8.5−41 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0860
s
® Selection list 1 CAN−OUT
Configuration of process output
words
See system
manual
(extension)
1 CAN−OUT1.W1 5001
2 CAN−OUT1.W2 1000 FIXED0%
3 CAN−OUT1.W3 1000 FIXED0%
4 CAN−OUT2.W1 1000 FIXED0%
5 CAN−OUT2.W2 1000 FIXED0%
6 CAN−OUT2.W3 1000 FIXED0%
7 CAN−OUT2.W4 1000 FIXED0%
8 CAN−OUT3.W1 1000 FIXED0%
9 CAN−OUT3.W2 1000 FIXED0%
10 CAN−OUT3.W3 1000 FIXED0%
11 CAN−OUT3.W4 1000 FIXED0%
C0861
s
® Selection list 3 CAN−OUT
Configuration of 32−bit angle
information
1 CAN−OUT1.D1 1000 FIXED0INC
2 CAN−OUT2.D1 1000 FIXED0INC
3 CAN−OUT3.D1 1000 FIXED0INC
C0863 g 0 1 CAN−IN
Display of process input words,
hexadecimal
See system
manual
(extension)
1 CAN−IN1 (0−15)
2 CAN−IN1
(16−31)
3 CAN−IN2 (0−15)
4 CAN−IN2
(16−31)
5 CAN−IN3 (0−15)
6 CAN−IN3
(16−31)
C0864 0
1
2 Analog signal
Digital 0−15
LOW angle CAN−OUT
Configuration of process output
words See system
manual
(extension)
1 CAN−OUT1.W2 0
2 CAN−OUT2.W1 0
3 CAN−OUT3.W1 0
C0865 0
1
2 Analog signal
Digital 16−31
HIGH angle CAN−OUT
Configuration of process output
words
1 CAN−OUT1.W3 0
2 CAN−OUT2.W2 0
3 CAN−OUT3.W2 0
