Configuration
Basic configurations
8
8.5
l
8.5−11 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0170
g Power−on time Fault memory − frequency
List of how often the faults
have occurred consecutively in
C0168
1 COUNTER ACT Currently active fault
2 COUNTER
OLD1
Last fault
... ... ...
8 COUNTER
OLD7
Seventh to last fault
C0172
s
OV REDUCE 0 0 {10 V} 100 OV reduce
Threshold for activating the
brake torque reduction before
OU message
C0173
s
UG LIMIT 1 Adjustment of the DC−bus
voltage
l Important! Check and, if
required, adapt during
commissioning!
l All drive components in the
interconnection must have
the same values!
See system
manual
(extension)
0 Mains<400V +−brake LU=285V,
OU=770V−755V Operation on mains <400 V
with or without braking unit
1 Mains=400V +−brake LU=285V,
OU=770V−755V Operation on 400 V mains with
or without braking unit
2 Mains=460V +−brake LU=328V,
OU=770V−755V Operation on 460 V mains with
or without braking unit
3 Mains=480V −brake LU=342V,
OU=770V−755V Operation on 480 V mains
without braking unit
4 Mains=480V +−brake LU=342V,
OU=800V−785V Operation on 480 V mains with
braking unit
C0178 OP TIMER g 0 {1 s} 4294967295 Operating time
Display of the time during
which the controller was
enabled
C0179 MAINS TIMER g 0 {1 s} 4294967295 Mains operating time
Display of the time during
which the mains was switched
on
C0182 TI S−SHAPED 20.00 0.01 {0.01 s} 50.00 NSET
T
i
time of the S shape ramp
function generator (determines
the form of the S−curve)
l Low values Þsmall S
rounding
l High values Þlarge S
rounding
See system
manual
(extension)
