Configuration
Basic configurations
8
8.5
l
8.5−67 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1363
g
−32768 {1} 32767 POS
Display of analog input signals
See system
manual
(extension)
1 POS−START−PS
2 POS−V−
OVERRID
3 POS−A−
OVERRID
4 POS−N−IN
5 POS−NOUT−GAI
N
6 POS−M−IN
7 POS−MOUT−GA
IN
8 POS−JERK−RED
C1364
s
® Selection list 3 POS
Configuration of input signals
See system
manual
(extension)
1 POS−PSET−EXT 1000 FIXED0INC
2 POS−ABS−IN 5000 MCTRL−PHI−ANG
3 POS−P−IN 1000 FIXED0INC
C1365 g −2147483647 {1 inc} 2147483647 POS
Display of input signals
See system
manual
(extension)
1 POS−PSET−EXT
2 POS−ABS−IN
3 POS−P−IN
C1370
s
® selection list 2 POS
Configuration of digital input
signals
See system
manual
(extension)
1 POS−PFI 20201 CAN−IN2.B0
2 POS−PFI 20202 CAN−IN2.B1
... ... ... ...
30 POS−PFI 20230 CAN−IN2.B29
31 POS−PFI 53 DIGIN3
32 POS−PFI 54 DIGIN4
C1371 g POS
Display of digital input signals
1 POS−PFI−LOW LOW−WORD
2 POS−PFI−HIGH HIGH−WORD
C1372 g POS
Display of digital input signals
1 POS−PFO−LOW LOW−WORD
2 POS−PFO−HIGH HIGH−WORD
C1380 g −214000.0000 {0.0001
units}
214000.0000 VTPOS
Display of the table position
with the position values
See system
manual
(extension)
1 VTPOS1
... ...
104 VTPOS104
C1381 g −2147483647 {1 inc} 2147483647 VTPOS
Display of the table positions
with the position values
1 VTPOS1
... ...
104 VTPOS104
