Lenze EVS9332xP - Manual (Page 354)

Configuration
Selection lists
Selection list 2: Digital output signals
8
8.6
8.6.2
l
8.6−4 EDSVS9332P EN 5.0−07/2013
Parameter Digital output signal ( G)
010600 NOT1−OUT
010605 NOT2−OUT
010610 NOT3−OUT
010615 NOT4−OUT
010620 NOT5−OUT
010650 CMP1−OUT
010655 CMP2−OUT
010700 DIGDEL1−OUT
010705 DIGDEL2−OUT
010750 TRANS1−OUT
010755 TRANS2−OUT
010900 FLIP1−OUT
010905 FLIP2−OUT
011000 CMPPH1−OUT
011005 CMPPH2−OUT
011010 CMPPH3−OUT
012000 PHINT1−FAIL
013000 FEVAN1−BUSY
013001 FEVAN1−FAIL
013005 FEVAN2−BUSY
013006 FEVAN2−FAIL
013010 FEVAN3−BUSY
013011 FEVAN3−FAIL
013015 FEVAN4−BUSY
013016 FEVAN4−FAIL
013020 FEVAN5−BUSY
013021 FEVAN5−FAIL
013025 FEVAN6−BUSY
013026 FEVAN6−FAIL
013050 BCD1−SEL1
013051 BCD1−SEL2
013052 BCD1−SEL3
013053 BCD1−SEL4
013054 BCD1−SEL5
013055 BCD1−SEL6
013056 BCD1−SEL7
013057 BCD1−SEL8
013058 BCD1−SIGN
013059 BCD1−NEW−DATA
013060 BCD1−EOT
013061 BCD1−DATA−FLT
013062 BCD1−BUSY
013063 BCD1−FAIL
013065 BCD2−SEL1
013066 BCD2−SEL2
013067 BCD2−SEL3
Parameter Digital output signal ( G)
013068 BCD2−SEL4
013069 BCD2−SEL5
013070 BCD2−SEL6
013071 BCD2−SEL7
013072 BCD2−SEL8
013073 BCD2−SIGN
013074 BCD2−NEW−DATA
013075 BCD2−EOT
013076 BCD2−DATA−FLT
013077 BCD2−BUSY
013078 BCD2−FAIL
013080 BCD3−SEL1
013081 BCD3−SEL2
013082 BCD3−SEL3
013083 BCD3−SEL4
013084 BCD3−SEL5
013085 BCD3−SEL6
013086 BCD3−SEL7
013087 BCD3−SEL8
013088 BCD3−SIGN
013089 BCD3−NEW−DATA
013090 BCD3−EOT
013091 BCD3−DATA−FLT
013092 BCD3−BUSY
013093 BCD3−FAIL
015000 DCTRL−TRIP
015001 DCTRL−MESS
015002 DCTRL−WARN
015003 DCTRL−FAIL
015004 DCTRL−FAILQSP
015010 MONIT−LU
015011 MONIT−OU
015012 MONIT−EEr
015013 MONIT−OC1
015014 MONIT−OC2
015015 MONIT−LP1
015016 MONIT−OH
015017 MONIT−OH3
015018 MONIT−OH4
015019 MONIT−OH7
015020 MONIT−OH8
015021 MONIT−Sd2
015022 MONIT−Sd3
015023 MONIT−P03
015024 MONIT−P13
015026 MONIT−CE0
