Commissioning
Switch−on sequence
Sequence diagram
6.3
6.3.1
l
6.3−1
EDSVS9332P EN 5.0−07/2013
6.3
Switch−on sequence
6.3.1
Sequence diagram
Switch on
controller
^ 6.3−1
Use existing
configuration?
Switch on PC, start
GDC
^ 6.3−1
yes
no
Re−establish
existing
positioning
Create new
positioning
Configure drive controller
1. Carry out basic settings (
^ 6.5−1)
2. Set speed feedback (
^ 6.6−1)
3. If required, adjust current controller (
^ 6.7−1)
4. If required, adjust rotor position (
^ 6.8−1)
5. Adapt assignment of control terminals (
^ 6.9−1)
Execute homing
(
^ 6.13−1)
Load parameter
set
(
^ 6.12−3)
Functional check of
manual control
(
^ 6.10−1)
Functional check of
manual control
(
^ 6.10−1)
Enter travel profile
parameters
(
^ 6.11−1)
Save parameter set
(
^ 6.12−1)
Control drive,
program control
(
^ 6.14−1)
Fig. 6.3−1
Commissioning sequence
