Configuration
Basic configurations
8.5
l
8.5−26
EDSVS9332P EN 5.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C0576
100.00 0.00
{0.01 %}
100.00 nErr monitoring speed window
Setting of the system deviation
between actual speed value
and speed setpoint
C0577 VP FLD WEAK
3.00
0.00
{0.01
ms]
15.99 Field weakening controller
V
p gain
C0578 TN FLD WEAK
50.0
2.0
{0.5 ms}
8192,0 Field weakening controller
Reset time Tn
C0578 = 8000 ms: Switched off
C0579 MONIT NERR
3
0
1
2
3
TRIP
Message
Warning
Off
nEEr monitoring
Configuration of "system
deviation between actual speed
value and speed setpoint"
monitoring
C0580 MONIT SD8
3
0
3
TRIP
Off
SD8 monitoring
Configuration of "Encoder error
at X8" monitoring
C0581 MONIT EER
0
0
1
2
3
TRIP
Message
Warning
Off
EEr monitoring
Configuration of "external
fault" monitoring
C0582 MONIT OH4
2
2
3
Warning
Off
OH4 monitoring
Configuration of heatsink
temperature monitoring
C0583 MONIT OH3
®
0
2
3
TRIP
Warning
Off
OH3 monitoring
Configuration of "fixed motor
temperature" monitoring
à
Depends on C0086
C0584 MONIT OH7
®
2
3
Warning
Off
OH7 monitoring
Configuration of "adjustable
motor temperature"
monitoring
à
Depends on C0086
Temperature monitoring via
resolver input
C0585 MONIT OH8
3
0
2
3
TRIP
Warning
Off
OH8 monitoring
Configuration of "adjustable
motor temperature"
monitoring
Temperature monitoring via
PTC input
C0586 MONIT SD2
0
0
2
3
TRIP
Warning
Off
SD2 monitoring
Configuration of resolver
monitoring
C0587 MONIT SD3
3
0
2
3
TRIP
Warning
Off
SD3 monitoring
Configuration of "encoder at
X9" monitoring
C0588 MONIT
H10/H11
0
0
2
3
TRIP
Warning
Off
H10/H11 monitoring
Setting C0588 = 2 or C0588 = 3
only allowed for Lenze service
C0589 MONIT P03
2
0
2
3
TRIP
Warning
Off
P03 monitoring
Configuration of following error
monitoring
l
The following error is
monitored by the DFSET
function block. The
monitoring is only active if
DFSET is used.
