Configuration
Basic configurations
8.5
l
8.5−8
EDSVS9332P EN 5.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C0108
100.00 −199.99
{0.01 %}
199.99 FCODE (AOUT gain)
Freely configurable code for
relative analog signals
See system
manual
(extension)
1 FCODE (GAIN)
AOUT1−GAIN
2 FCODE (GAIN)
AOUT2−GAIN
C0109
−199.99
{0.01 %}
199.99 FCODE (offset AOUT)
Freely configurable code for
relative analog signals
See system
manual
(extension)
1 FCODE
(OFFSET)
0.00
AOUT1−OFFSET
2 FCODE
(OFFSET)
0.00
AOUT2−OFFSET
C0114
0
1
HIGH active
LOW active
DIGIN polarity
Polarity of the terminals X5/Ex
See system
manual
(extension)
1 DIGIN1 POL
1
X5/E1
2 DIGIN2 POL
1
X5/E2
3 DIGIN3 POL
0
X5/E3
4 DIGIN4 POL
0
X5/E4
5 DIGIN5 POL
0
X5/E5
C0116
s
® selection list 2 Signal configuration of the free
digital outputs (FDO)
Free digital outputs can only be
evaluated when they are linked
to automation interfaces
See system
manual
(extension)
1 FDO−00
1000
FIXED0
2 FDO−01
15000 DCTRL−TRIP
3 FDO−02
30002 ENDED
4 FDO−03
30014 VTRAV−REA
5 FDO−04
30104 PF04
... ...
...
...
10 FDO−09
30109 PF09
11 FDO−10
30110 PF10
12 FDO−11
30111 PF11
... ...
...
...
21 FDO−20
30120 PF20
22 FDO−21
30121 PF21
... ...
...
...
31 FDO−30
30130 PF30
32 FDO −31
30131 PF31
33 FDO−32
30132 PF32
C0117
s
®
® selection list 2 Signal configuration DIGOUT
à
depending on C0005
See system
manual
(extension)
1 DIGOUT1
30012 pos−ref−ok
X5/A1
2 DIGOUT2
30013 POS−IN−TARGET
X5/A2
3 DIGOUT3
500
DCTRL−RDY
X5/A3
4 DIGOUT4
30101 pos−pfo1
X5/A4
C0118
0
1
HIGH active
LOW active
DIGOUT polarity
Polarity of the terminals X5/Ax
See system
manual
(extension)
1 DIGOUT1 POL
0
X5/A1
2 DIGOUT2 POL
0
X5/A2
3 DIGOUT3 POL
0
X5/A3
4 DIGOUT4 POL
0
X5/A4
