Configuration
Basic configurations
8.5
l
8.5−75
EDSVS9332P EN 5.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C1582
s
CONVAD2−IN
1000
FIXED0%
® Selection list 1 CONVAD2
Configuration − analog input
signal
See system
manual
(extension)
C1583 CONVAD2−IN
g
−32768
{1}
32767 CONVAD2
Display of analog input signal
C1590 CONVAPH1
NUMERATOR
1
−32767
{1}
32767 CONVAPH1
Numerator
See system
manual
(extension)
C1591 CONVAPH1
DENUMERATO
R
1
1
{1}
32767 CONVAPH1
Denominator
C1593
s
CONVAPH1−IN
1000
FIXED0%
® Selection list 1 CONVAPH1
Configuration − analog input
signal
C1594 CONVAPH1−IN
g
−32768
{1}
32767 CONVAPH1
Display of analog input signal
C1595 CONVAPH2
NUMERATOR
1
−32767
{1}
32767 CONVAPH2
Numerator
See system
manual
(extension)
C1596 CONVAPH2
DENUMERATO
R
1
1
{1}
32767 CONVAPH2
Denominator
C1598
s
CONVAPH2−IN
1000
FIXED0%
® Selection list 1 CONVAPH2
Configuration − analog input
signal
C1599 CONVAPH2−IN
g
−32768
{1}
32767 CONVAPH2
Display of analog input signal
C1600 CONVAPH3
NUMERATOR
1
−32767
{1}
32767 CONVAPH3
Numerator
See system
manual
(extension)
C1601 CONVAPH3
DENUMERATO
R
1
1
{1}
32767 CONVAPH3
Denominator
C1603
s
CONVAPH3−IN
1000
FIXED0%
® Selection list 1 CONVAPH3
Configuration − analog input
signal
C1604 CONVAPH3−IN
g
−32768
{1}
32767 CONVAPH3
Display of analog input signal
C1610
1
0
{1}
31 CONVPHA2
Division factor
See system
manual
(extension)
C1611
s
CONVPHA2−IN
1000
FIXED0INC
® Selection list 3 CONVPHA2
Configuration of input signal
C1612 CONVPHA2−IN
g
CONVPHA2
Display of input signal
C1615
1
0
{1}
31 CONVPHA3
Division factor
See system
manual
(extension)
C1616
s
CONVPHA3−IN
1000
FIXED0INC
® Selection list 3 CONVPHA3
Configuration of input signal
C1617 CONVPHA3−IN
g
CONVPHA3
Display of input signal
