Lenze EVS9332xP - Manual (Page 342)

Configuration
Basic configurations
8
8.5
l
8.5−76 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1640
s
SP1−RESET 1000 FIXED0 ® selection list 2 SP1
Configuraton of digital input
signal
See system
manual
(extension)
C1641 0
1
...
104 Real zero
VTPOS−No 001
...
VTPOS−No 104 SP1
1 SP1−VALUE 1−1 1 Switching point output
SP1−STAT1
2 SP1−VALUE 1−2 1
3 SP1−VALUE 2−1 1 Switching point output
SP1−STAT2
4 SP1−VALUE 2−2 1
5 SP1−VALUE 3−1 1 Switching point output
SP1−STAT3
6 SP1−VALUE 3−2 1
7 SP1−VALUE 4−1 1 Switching point output
SP1−STAT4
8 SP1−VALUE 4−2 1
9 SP1−VALUE 5−1 1 Switching point output
SP1−STAT5
10 SP1−VALUE 5−2 1
11 SP1−VALUE 6−1 1 Switching point output
SP1−STAT6
12 SP1−VALUE 6−2 1
13 SP1−VALUE 7−1 1 Switching point output
SP1−STAT8
14 SP1−VALUE 7−2 1
15 SP1−VALUE 8−1 1 Switching point output
SP1−STAT8
16 SP1−VALUE 8−2 1
C1642
s
SP1−L−IN 1000 FIXED0INC ® Selection list 3 SP1
Configuration of input signal
C1643 SP1−RESET g 0 1 SP1
Display of digital input signal
C1644 SP1−L−IN g −1073741824 {1 inc} 1073741823 SP1
Display of input signal
C1645 SP1−MODE 0 0 Starting point and final point SP1
Setting of the switching points
1 Centre with switch range
