Configuration
Basic configurations
8
8.5
l
8.5−56 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1220 g −214000
.0000 {0.0001 units} 214000.
0000
POS
Display in units See system
manual
(extension)
1 POS−TARGET Actual target position
2 POS−SETPOS Actual position setpoint
3 POS−ACTPOS Actual position
4 ACT.FOLLOW
ERR
Actual following error
5 ACTPOS ABS. Actual position (absolute value)
6 REFMARK
0−IMP
Distance between REF−MARK
and index pulse
7 ACT.HOME
OFFS
Actual reference dimension
offset
8 ACT.HOME
POS.
Actual home position
9 ACT. WAY Actual path (path still to be
positioned)
10 ACT. C1223 Real internal values of codes
C1223, C1224, C1240, C1250
(internal limitation possible:
see error message P18 in the
chapter "Troubleshooting and
fault messages
11 ACT. C1224
12 ACT. C1240
13 ACT. C1250
14 ACT. VNORM Actual value Vnorm
Internal value for fault analysis
15 ACT. ANORM Actual value Anorm
Internal value for fault analysis
16 POS−ABS−VAL Actual position (without offset)
C1221 g −2147483647 {1 inc} 2147483647 POS
Display in increments
See system
manual
(extension)
1 POS−TARGET Actual target position
2 POS−SETPOS Actual position setpoint
3 POS−ACTPOS Actual position
4 ACT.FOLLOW
ERR
Actual following error
5 ACTPOS ABS. Read in absolute value
6 REFMARK
0−IMP
Distance of REF−MARK to index
pulse
7 ACT.HOME
OFFS
Actual reference dimension
offset
8 ACT.HOME
POS.
Actual home position
9 ACT. WAY Path still to be positioned
10 ACT. C1223 Real internal values of codes
C1223, C1224, C1240, C1250
(internal limitation possible:
see error message P18 in the
chapter "Troubleshooting and
fault messages
11 ACT. C1224
12 ACT. C1240
13 ACT. C1250
14 ACT. VNORM Actual value Vnorm
Internal value for fault analysis
15 ACT. ANORM Actual value Anorm
Internal value for fault analysis
16 POS−ABS−VAL Actual position (without offset)
