Configuration
Basic configurations
8.5
l
8.5−63
EDSVS9332P EN 5.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C1329
0
1
2
3
...
32
Prg.−end
PS 01
PS 02
PS 03
...
PS 32
POS
Branch to a program set if the
piece number selected in VTPCS
(C1328) has not been reached
yet
See system
manual
(extension)
1 JMP−PCS−PS
0
2 JMP−PCS−PS
0
... ...
...
32 JMP−PCS−PS
0
C1330
0
1
2
3
...
104
Travel range
VTPOS−No 001
VTPOS−No 002
VTPOS−No 003
...
VTPOS−No 104
Touch probe window
Selection of a window for touch
probe. In this area the touch
probe is "sharp".
1 TP WINDOW
0
2 TP WINDOW
0
... ...
...
32 TP WINDOW
0
C1331
0
1
2
3
...
104
Target = TP position
VTPOS−No 001
VTPOS−No 002
VTPOS−No 003
...
VTPOS−No 104
Residual touch probe path
Selection of a residual path
from VTPOS for touch probe
1 TP DISTANCE
0
2 TP DISTANCE
0
... ...
...
32 TP DISTANCE
0
C1333
0
1
2
3
...
32
Prg.−end
PS 01
PS 02
PS 03
...
PS 32
POS
Branch to a program set if no
touch probe has occurred until
the target position (C1312) is
reached
See system
manual
(extension)
1 JMP−TP−PS
0
2 JMP−TP−PS
0
... ...
...
32 JMP−TP−PS
0
C1334
0
1
2
...
32
Inactive
PFI 01
PFI 02
...
PFI 32
POS
Number of a PFI for branch 2
See system
manual
(extension)
1 JMP2−PFI−NO
2 JMP2−PFI−NO
... ...
32 JMP2−PFI−NO
C1335
0
1
LOW level
HIGH level
POS
Level of a PFI for branch 1
See system
manual
(extension)
1 JMP2−LEVEL
0
2 JMP2−LEVEL
0
... ...
...
32 JMP2−LEVEL
0
C1336
0
1
2
3
...
32
Prg.−end
PS 01
PS 02
PS 03
...
PS 32
POS
Branch 2 to a program set
See system
manual
(extension)
1 JMP2−PS
0
2 JMP2−PS
0
... ...
...
32 JMP2−PS
0
C1349
0
1
2
3
...
32
Prg.−end
PS 01
PS 02
PS 03
...
PS 32
POS
Unconditional branch to a
program set
See system
manual
(extension)
1 JMP−PS
0
2 JMP−PS
0
... ...
...
32 JMP−PS
0
