Wiring of the standard device
Control terminals
Terminal assignment
5
5.8
5.8.6
l
5.8−9 EDSVS9332P EN 5.0−07/2013
5.8.6 Terminal assignment
Terminal Jumper strip
X3
Jumper setting Possible levels
X6/1,
X6/2
1
3
5
2
4
6 1−2 1) −10 V ... +10 V 1)
3−4 −10 V ... +10 V
5−6 −20 mA ... +20 mA
1) Lenze setting (delivery state)
Terminal Description Function Level / state
X11/K32
X11/K31 Safety relay K
SR
1st
disconnecting
path
Pulse inhibit feedback Open contact: pulse
inhibit is inactive
(operation)
Closed contact:
pulse inhibit is active
X11/33 – coil of safety relay K
SR
Coil is not carrying
any current: pulse
inhibit is active
X11/34 + coil of safety relay K
SR
Coil is carrying
current: pulse inhibit
is inactive
(operation)
X5/28 Controller
inhibit
(DCTRL−CINH)
2nd
disconnecting
path Controller enable/inhibit LOW: Controller
inhibited
HIGH: Controller
enabled
X5/ST1
X5/ST2 STATE−BUS
Terminal Description Function Level
X5/E1 Digital inputs Limit switch, negative side (POS−LIM−NEG) LOW
X5/E2 Limit switch, positive side (POS−LIM−POS) LOW
X5/E3 Start positioning program (POS−PRG−START) LOW−HIGH edge
X5/E4 Reference switch (POS−REF−MARK) and
touch probe input HIGH
X5/E5 Reset TRIP error message (DCTRL−TRIP−RES) LOW−HIGH edge
Reset positioning program (PRG−RESET) HIGH
Activate manual operation (POS−MANUAL) HIGH
X5/A1 Digital outputs Reference known (POS−REF−OK) HIGH
X5/A2 Position target reached (POS−IN−TARGET) HIGH
X5/A3 Ready for operation (DCTRL−RDY) HIGH
X5/A4 Program function output (POS−PFO1)
(output can be switched via the positioning
program) HIGH
X6/1,
X6/2 Analog inputs None −10 V ... +10 V
X6/3,
X6/4 None −10 V ... +10 V
X6/62 Analog outputs Actual speed value (MCTRL−NACT) −10 V ... +10 V
X6/63 Torque setpoint (MCTRL−MSET2) −10 V ... +10 V
Analog input configuration
Non−configurable control
terminals
Configurable control
terminals (Lenze setting)
