Configuration
Basic configurations
8
8.5
l
8.5−40 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0850
s
® Selection list 1 AIF−OUT
Configuration process output
words for automation interface
AIF (X1)
See system
manual
(extension)
1 AIF1OUT.W1 1000 FIXED0%
2 AIF−OUT.W2 1000 FIXED0%
3 AIF−OUT.W3 1000 FIXED0%
C0851
s
AIF−OUT.D1 1000 FIXED0INC ® Selection list 3 AIF−OUT
Configuration of 32−bit angle
information
C0852 AIF−TYPE
OUT.W2
0 0
1
2
3 Analog signal
Digital 0−15
D1: LOW angle
D2: HIGH angle AIF−OUT
Configuration process output
word 2 for automation
interface AIF (X1)
C0853 AIF−TYPE
OUT.W3
0 0
1
2 Analog signal
Digital 16−31
HIGH angle AIF−OUT
Configuration − process output
word 3 for automation
interface AIF (X1)
C0854 AIF−TYPE
OUT.W1
0 0
3 Analog signal
D2: LOW phase AIF−OUT
Configuration process output
word 1 for automation
interface AIF (X1)
C0855 g AIF−IN
Process input words
hexadecimal for automation
interface X1 See system
manual
(extension)
1 AIF−IN (0−15) Bit 00 {1} Bit 15
2 AIF−IN (16−31) 16 bit {1} Bit 31
C0856
g
−199 {1 %} 199 AIF−IN
Decimal process input words
Display: 100.00 % = 16384
1 AIF−IN.W1
2 AIF−IN.W2
3 AIF−IN.W3
C0857 AIF−IN.D1 g −2147483648 {1} 2147483647 AIF−IN
32−bit phase information
C0858
g
−199.99 {0.01 %} 199.99 AIF−OUT
Process output words
Display: 100 % = 16384
See system
manual
(extension)
1 AIF−OUT.W1
2 AIF−OUT.W2
3 AIF−OUT.W3
C0859 AIF−OUT.D1 g −2147483648 {1} 2147483647 AIF−OUT
32−bit phase information
