IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C1405
s
® Selection list 1 TEACH1
Configuration − analog input
signal
See system
manual
(extension)
1 TEACH1−LDVAL
1000
FIXED0%
C1406
g
−32768
{1}
32768 TEACH1
Display of analog input signal
1 TEACH1−LDVAL
C1500 OUTPUT
SIGNAL
g
−2147483648
{1}
2147483647 FEVAN2
Signal output
See system
manual
(extension)
C1501 FEVAN2 CODE
141
2
{1}
2000 FEVAN2
Target code of FEVAN2
C1502 FEVAN2
SUBCODE
0
0
{1}
255 FEVAN2
Target subcode FEVAN2
C1503 FEVAN2
NUMERATOR
1.0000 0.0001
{0.0001}
100000.0000 FEVAN2
Numerator
C1504 FEVAN2
DENOMINATO
R
0.0001 0.0001
{0.0001}
100000.0000 FEVAN2
Denominator
C1505 FEVAN2
OFFSET
0
0
1000000000 FEVAN2
Offset
C1506
s
FEVAN2−IN
1000
FIXED0%
® Selection list 1 FEVAN2
Configuration − analog input
signal
See system
manual
(extension)
C1507
s
® selection list 2 FEVAN2
Configuration of digital input
signals
1 FEVAN2−LOAD
1000
FIXED0
2 FEVAN2−
BUSY−IN
1000
FIXED0
3 FEVAN2−FAIL−I
N
1000
FIXED0
C1508 FEVAN2−IN
g
−32768
{1}
32767 FEVAN2
Display of analog input signal
C1509
g
FEVAN2
Display of digital input signals
1 FEVAN2−LOAD
2 FEVAN2−
BUSY−IN
3 FEVAN2−FAIL−I
N
C1510 OUTPUT
SIGNAL
−2147483648
{1}
2147483647 FEVAN3
Signal output
See system
manual
(extension)
C1511 FEVAN3 CODE
141
2
{1}
2000 FEVAN3
Target code of FEVAN3
C1512 FEVAN3
SUBCODE
0
0
{1}
255 FEVAN3
Target subcode FEVAN3
C1513 FEVAN3
NUMERATOR
1,0000 0.0001
{0.0001}
100000,0000 FEVAN3
Numerator
C1514 FEVAN3
DENOMINATO
R
0,0001 0,0001
{0,0001}
100000,0000 FEVAN3
Denominator
C1515 FEVAN3
OFFSET
0
0
1000000000 FEVAN3
Offset
