Configuration
Basic configurations
8
8.5
l
8.5−50 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1124
s
SYNC1−IN1 1000 FIXED0% ® Selection list 1 SYNC1
Configuration − analog input
signal
See system
manual
(extension)
C1125
s
SYNC1−IN2 1000 FIXED0INC ® Selection list 3 SYNC1
Configuration of input signal
C1126
s
SYNC1−IN3 1000 FIXED0% ® Selection list 1 SYNC1
Configuration − analog input
signal
C1127 SYNC1−IN1 g −2147483647 {1} 2147483647 SYNC1
Display of analog input signal
C1128 SYNC1−IN2 g −2147483647 {1} 2147483647 SYNC1
Display of input signal
C1129 SYNC1−IN3 g −2147483647 {1} 2147483647 SYNC1
Display of analog input signal
C1130
s
® Selection list 1 CONVPHPH2
Configuration of analog input
signals
See system
manual
(extension)
1 CONVPHPH2−
NUM
1000 FIXED0%
2 CONVPHPH2−
DEN
1000 FIXED0%
C1131
s
CONVPHPH2−
ACT 1000 FIXED0 ® selection list 2 CONVPHPH2
Configuraton of digital input
signal
C1132
s
CONVPHPH2−
IN2 1000 FIXED0INC ® Selection list 3 CONVPHPH2
Configuration of input signal
C1135 g CONVPHPH2
Display of analog input signals
1 CONVPHPH2−
NUM
2 CONVPHPH2−
DEN
C1136 CONVPHPH2−
ACT
g CONVPHPH2
Display of digital input signal
C1137 CONVPHPH2−
IN2
g −2147483647 {1} 2147483647 CONVPHPH2
Display of input signal
C1160
s
® Selection list 1 ASW3
Configuration of analog input
signals
See system
manual
(extension)
1 ASW3−IN1 1000 FIXED0%
2 ASW3−IN2 1000 FIXED0%
C1161
s
ASW3−SET 1000 FIXED0 ® selection list 2 ASW3
Configuraton of digital input
signal
C1162 g −199.99 {0.01 %} 199.99 ASW3
Display of analog input signals
1 ASW3−IN1
2 ASW3−IN2
C1163 ASW3−SET g ASW3
Display of digital input signal
