Configuration
Basic configurations
8
8.5
l
8.5−44 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0901
s
MCTRL−I−SET 1000 FIXED0% ® Selection list 1 MCTRL
Configuration of input signal
for loading the I component for
the speed controller
See system
manual
(extension)
C0902
s
MCTRL−I−LOAD 1000 FIXED0 ® selection list 2 MCTRL
Configuration of tripping signal
for loading the I component for
the speed controller
C0903
s
MCTRL−P−ADAP
T 1006 FIXED100% ® Selection list 1 MCTRL
Configuration of input signal
for adaption of the angle
controller
C0906
g
−199.99 {0.01 %} 199.99 MCTRL
Display of analog input signals
See system
manual
(extension)
1 MCTRL−N−SET
2 MCTRL−M−ADD
3 MCTRL−LO−M−L
IM
4 MCTRL−HI−M−LI
M
5 MCTRL−PHI−LI
M
6 MCTRL−N2−LIM
7 MCTRL−FLD−WE
AK
8 MCTRL−I−SET
9 MCTRL−P−ADAP
T
C0907 g MCTRL
Digital input signals See system
manual
(extension)
1 MCTRL−PHI−ON
2 MCTRL−N/M−S
WT
3 MCTRL−QSP
4 MCTRL−I−LOAD
C0908 MCTRL−PHI−SET g −2147483647 {1 inc} 2147483647 MCTRL
Display of setpoint angle signal
l 1 rev. = 65536 inc
C0909 SPEED LIMIT 1 1
2
3 +/− 175 %
0 ... +175 %
−175 ... 0 % MCTRL
Rotating direction limitation for
speed setpoint
C0940 CONV1−
NUMERATOR
1 −32767 {1} 32767 CONV1
Numerator
See system
manual
(extension)
C0941 CONV1−DENO
MINATOR
1 1 {1} 32767 CONV1
Denominator
C0942
s
CONV1−IN 1000 FIXED0% ® Selection list 1 CONV1
Configuration of analog input
C0943 CONV1−IN g −199.99 {0.01 %} 199.99 CONV1
Display of analog input signal
C0945 CONV2−
NUMERATOR
1 −32767 {1} 32767 CONV2
Numerator
See system
manual
(extension)
C0946 CONV2−DENO
MINATOR
1 1 {1} 32767 CONV2
Denominator
C0947
s
CONV2−IN 1000 FIXED0% ® Selection list 1 CONV2
Configuration of analog input
C0948 CONV2−IN g −199.99 {0.01 %} 199.99 CONV2
Display of analog input signal
