Lenze EVS9332xP - Manual (Page 318)

Configuration
Basic configurations
8
8.5
l
8.5−52 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1181 ID STATE g
Status of the control parameter
identification
0 Not activated / completed
1 Busy Control parameters are
identified
2 Error: Calculation not possible
(C1187/C1188) Control parameter calculation
not possible
l Check whether the plant
parameters are set
reasonably (C1187/C1188)
3 Error: Identification not possible
(C1182−C1185) Too few scanning points
registered
l Change basic conditions of
the movement
(C1182−C1185)
– Increase torque, increase
number of revolutions,
increase speed, reduce
torque rise time
4 Error: Reference torque C0057 too low Reference torque too low
l Increase I
max
(C0022)
l Check max. torque (C0057)
5 Error: Speed at start not zero Speed at start ¹ 0
l Stop drive and reactivate
function
6 Error: Controller inhibit during motion Controller inhibit during
motion
l Repeat identification
7 Error: Torque ramp in C1185 too long Minimum braking torque not
reached, torque ramp too flat,
or max. torque too low
l Change basic conditions of
the movement
(C1182−C1185)
– Increase torque, increase
number of revolutions,
increase speed, reduce
torque rise time
8 Error: Identification too long
(C1184−C1185) Time overflow
l Increase torque, reduce
torque rise time
9 Error: Unfavourable entries
(C1182−C1185) Blocking
l Release brake, check motor
cable, eliminate blocking
10 Waiting for enable to start the
movement
11 Waiting for end of movement
12 Waiting for controller inhibit for
completion
99 Internal error
C1182 PHI−ID PHASE 100.0 0.5 {0.1 rev} 3000.0 Control parameter
identification
l Selection of the number of
revolutions
C1183 N−ID MAX 100 10 {1 %} 100 Control parameter
identification
l Selection of the speed
l 100 % = n
max
