Configuration
Basic configurations
8
8.5
l
8.5−23 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0517 0.00 {0.01} 1999.00 User menu
Up to 32 entries
l Under the subcodes the
numbers of the desired code
are entered
l The input is effected in the
format xxx.yy
– xxx: Code number
– yy: Subcode number
l It is not checked whether
the code entered exists
1 USER MENU 51.00 C0051/0 MCTRL−NACT
2 USER MENU 54.00 C0054/0 Imot
3 USER MENU 56.00 C0056/0 MCTRL−MSET2
4 USER MENU 46.00 C0046/0 N
5 USER MENU 49.00 C0049/0 NADD
6 USER MENU 183.00 C0183/0 Diagnostics
7 USER MENU 168.01 C0168/1 Fail no. act
8 USER MENU 86.00 C0086/0 Mot type
9 USER MENU 22.00 C0022/0 Imax current
10 USER MENU 5.00 C005/0 signal cfg
11 USER MENU 11,00 C0011/0 Nmax
12 USER MENU 12.00 C0012/0 T
ir
13 USER MENU 13.00 C0013/0 T
if
14 USER MENU 105.00 C0105/0 QSP T
if
15 USER MENU 39.01 C0039/1 JOG setpoint
16 USER MENU 70.00 C0070/0 Vp speed CTRL
17 USER MENU 71.00 C0071/0 Tn speed CTRL
18 USER MENU 0 Not assigned
... ... 0 Not assigned
31 USER MENU 94.00 C0094/0 Password
32 USER MENU 3.00 C0003/0 Par save
C0520
s
DFSET−IN 1000 FIXEDPHI−0 ® Selection list 4 DFSET
Configuration of input signal
See system
manual
(extension)
C0521
s
DFSET−VP−DIV 1000 FIXED0% ® Selection list 1 DFSET
Configuration of gain factor
numerator
See system
manual
(extension)
C0522
s
DFSET−RAT−DIV 1000 FIXED0% ® Selection list 1 DFSET
Configuration of gearbox factor
numerator
C0523
s
DFSET−A−TRIM 1000 FIXED0% ® Selection list 1 DFSET
Configuration of phase
trimming
C0524
s
DFSET−N−TRIM 1000 FIXED0% ® Selection list 1 DFSET
Speed trimming of DFSET
C0525
s
DFSET−0−PULSE 1000 FIXED0 ® selection list 2 DFSET
Configuration of one−time zero
pulse activation
See system
manual
(extension)
C0526
s
DFSET−RESET 1000 FIXED0 ® selection list 2 DFSET
Integrator resetting
C0527
s
DFSET−SET 1000 FIXED0 ® selection list 2 DFSET
Configuration of integrator
setting
