Configuration
Basic configurations
8
8.5
l
8.5−25 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0545 DFOUT−PH
OFFSET
0 0 {1 inc} 65535 DFOUT
Angular offset
See system
manual
(extension)
C0546 DFOUT−MIN
INC/REV
1000 −245760000 {1inc} 245760000 DFOUT
Masking (suppressing)
interference pulses at X5/E5
(set pulse of touch probe signal)
l The size of the masking
window between two set
pulses is set
C0547 DFOUT−AN−IN g −199.99 {0.01 %} 199.99 DFOUT
Display of analog input signal
See system
manual
(extension)
C0548 DFOUT−SYN−
RDY
g 0 1 DFOUT
Display of digital input signal
C0549 DFOUT−DF−IN g −32767 {1 rpm} 32767 DFOUT
Display of input signal
C0560 −199.99 {0.01 %} 199.99 FIXSET1
Fixed setpoints
See system
manual
(extension)
1 FIXSET1−VALUE 100
2 FIXSET1−VALUE 75
3 FIXSET1−VALUE 50
4 FIXSET1−VALUE 25
5 FIXSET1−VALUE 0
... ... ...
15 FIXSET1−VALUE 0
C0561
s
FIXSET1−AIN 1000 FIXED0% ® Selection list 1 FIXSET1
Configuration − analog input
signal
C0562
s
® selection list 2 FIXSET1
Configuration of digital input
signals
1 FIXSET1−IN1 1000 FIXED0
2 FIXSET1−IN2 1000 FIXED0
3 FIXSET1−IN3 1000 FIXED0
4 FIXSET1−IN4 1000 FIXED0
C0563 FIXSET1−AIN g −199.99 {0.01 %} 199.99 FIXSET1
Display of analog input signal
C0564 g FIXSET1
Display of digital input signals
1 FIXSET1−IN1
2 FIXSET1−IN2
3 FIXSET1−IN3
4 FIXSET1−IN4
C0570
s
S&H1−IN 1000 FIXED0% ® Selection list 1 S&H1
Configuration − analog input
signal
See system
manual
(extension)
C0571
s
S&H1−LOAD 1000 FIXED0 ® selection list 2 S&H1
Configuraton of digital input
signal
C0572 S&H1−IN g −199.99 {0.01 %} 199.99 S&H1
Display of analog input signal
C0573 S&H1−LOAD g S&H1
Display of digital input signal
C0575 SD8 FILTER 1 1 {1 ms} 200 SD8 monitoring
Tripping delay of error message
SD8
