Configuration
Basic configurations
8
8.5
l
8.5−33 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0741 OSC See system
manual
(extension)
1 VERSION OSC g Version
2 LENGTH
MEMORY
Memory size
3 DATA WIDTH Data width
4 NO. CHANNELS Number of channels
C0742 LENGTH OF DB g OSC
Show data block length
C0743 READ DB g OSC
Reading of an 8−byte data block
C0744 MEM: DEPTH 2048 0
1
2
3
4
5
6 512 measured values
1024 measured values
1536 measured values
2048 measured values
3072 measured values
4096 measured values
8192 measured values OSC
Adapt memory depth to the
measuring task
C0749 g OSC
Information on the storage of
the measured values See system
manual
(extension)
1 BRK:OFF INDEX
2 TRIGGER
INDEX
3 END INDEX
C0750 DFRFG1−VP
DENOM
16 1
2
4
8
16
34
64
128
256
512
1024
2048
4096
8192
16384 V
p
= 1
V
p
= 1/2
V
p
= 1/4
V
p
= 1/8
V
p
= 1/16
V
p
= 1/32
V
p
= 1/64
V
p
= 1/128
V
p
= 1/256
V
p
= 1/512
V
p
= 1/1024
V
p
= 1/2048
V
p
= 1/4096
V
p
= 1/8192
V
p
= 1/16384
DFRFG1
Denominator of the position
controller gain V
p
See system
manual
(extension)
C0751 DFRFG1−
DFRFG1 TIR
1.000 0.001 {0.001
s}
999.900 DFRFG1
Acceleration time T
ir
See system
manual
(extension)
C0752 DFRFG1−MAX
SPEED
3000 1 {1 rpm} 16000 DFRFG1
Maximum speed (here:
maximum compensation
speed)
C0753 DFRFG1−
DFRFG1 QSP
0.000 0.000 {0.001
s}
999.900 DFRFG1
Deceleration time T
if
if the
deceleration ramp is activated
C0754 DFRFG1−PH
ERROR
2 . 10 9 10 {1} 2 . 10 9 DFRFG1
Following error
C0755 SYN WINDOW 100 0 {1 inc} 65535 DFRFG1
Synchronisation window
