IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1090 FEVAN1−OUTP
UT SIGNAL
g −2147483648 {1} 2147483647 FEVAN1
Display of output signal
See system
manual
(extension)
C1091 FEVAN1−CODE 141 2 {1} 2000 FEVAN1
Selection target code
C1092 FEVAN1−SUBC
ODE
0 0 {1} 255 FEVAN1
Selection of the target subcode
C1093 FEVAN1−
NUMERATOR
1.0000 0.0001 {0.0001} 100000,0000 FEVAN1
Numerator
C1094 FEVAN1−DENO
MIATOR
0.0001 0.0001 {0.0001} 100000,0000 FEVAN1
Denominator
C1095 FEVAN1−OFFSE
T
0 0 {1} 1000000000 FEVAN1
Offset setting
C1096
s
FEVAN1−IN 1000 FIXED0% ® Selection list 1 FEVAN1
Configuration − analog input
signal
See system
manual
(extension)
C1097
s
® selection list 2 FEVAN1
Configuration of digital input
signals
1 FEVAN1−LOAD 1000 FIXED0
2 FEVAN1−
BUSY−IN
1000 FIXED0
3 FEVAN1−FAIL−I
N
1000 FIXED0
C1098 FEVAN1−IN g −32768 {1} 32767 FEVAN1
Display of analog input signal
See system
manual
(extension)
C1099 g FEVAN1
Display of digital input signals
1 FEVAN1−LOAD
2 FEVAN1−
BUSY−IN
3 FEVAN1−FAIL−I
N
C1100 FCNT1−
FUNCTION
1 FCNT1
Function selection See system
manual
(extension)
1 Return If |counter
content|
³ |FCNT1−CMP−Val|,
FCNT1−EQUAL is set to HIGH for
1 ms
2 Hold if >= If |counter
content|
³ |FCNT1−CMP−Val|,
the counter stops
3 Hold if = If |counter
content| = |FCNT1−CMP−Val|,
the counter stops
C1101
s
® Selection list 1 FCNT1
Configuration of analog input
signals
See system
manual
(extension)
1 FCNT1−LD−VAL 1000 FIXED0%
2 FCNT1−CMP−V
AL
1000 FIXED0%
C1102
s
® selection list 2 FCNT1
Configuration of digital input
signals
1 FCNT1−CLKUP 1000 FIXED0
2 FCNT1−
CLKDWN
1000 FIXED0
3 FCNT1−LOAD 1000 FIXED0
