Configuration
Basic configurations
8
8.5
l
8.5−54 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1204 FEED
CONSTANT
1.0000 0.0001 {0.0001} 214000,0000 Feed constant
l Feed of the machine in units
per revolution of the load
side of the gearbox.
See system
manual
(extension)
C1205 POS. RESOLUT. g 0 {0.0001 inc/unit} 214000.
0000
Position resolution
l The position resolution
indicates the number of
increments which resolve a
unit determined by the user.
See system
manual
(extension)
C1206
s
SET POLARITY 0 0
1 Not inverted
Inverted Polarity of position setpoint
l Reversal of the position
direction
See system
manual
(extension)
C1207 1 {1} 65335 Position encoder − gearbox
factor
l Gearbox factor between
motor and position encoder
l Numerator/denominator
corresponds to motor
speed/encoder speed
l Encoder to motor shaft: 1/1
See system
manual
(extension)
1 FDBK RAT
NUM
1
2 FDBK RAT DEN 1
C1208 ACT POLARITY 0 0
1 Not inverted
Inverted Polarity − actual position
l >Inversion of the actual
position, e.g. when using a
separate position encoder
behind the gearbox.
See system
manual
(extension)
C1209 REF
END−POINT
0 0
1
61
71
101 Ref−point
Real−0
VTPOS−No 060
VTPOS−No 070
VTPOS−No 100 Homing end point
l Point where the drive is to
be positioned after homing
See system
manual
(extension)
C1210 POS. MODE 0 0
1
2 Absolute positioning
Relative positioning
Absolute positioning with saving Positioning mode
l If C1210 = 0, relative and
absolute positioning
processes can be carried out
l If C11210 = 1, only relative
positioning processes can be
carried out
See system
manual
(extension)
C1211 START PS NO. 1 1 {1} 32 Program set number
l Program set with which
processing of the
positioning program is to be
started
l The program start is
effected after an edge at the
input "PRG−START"
See system
manual
(extension)
C1212 ACT. PS NO. g 0
1
2
...
31
32 Prog. end
PS 01
PS 02
...
PS 31
PS 32 Program set number
l Display of the actual
program set number
See system
manual
(extension)
