Configuration
Basic configurations
8
8.5
l
8.5−6 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0076 TN CURR CTRL 1.8 0.5 {0.1 ms} 2000,0 T
ni
current controller
At 2000 ms the function is
deactivated
l Depends on C0086
l Change of C0086 resets
value to the assigned Lenze
setting
C0077 VP FIELD CTRL 0.25 0.00 {0.01} 15.99 V
pF
field controller
C0078 TN FIELD CTRL 15.0 1.0 {0.5 ms} 7999,0 T
nF
field controller
At 8000 ms the function is
deactivated
C0081
s
MOT POWER à 0.01 {0.01 kW} 150.00 Rated motor power
à Depends on C0086
l Change of C0086 resets
value to the assigned Lenze
setting
l Change of C0081 sets C0086
= 0
C0084
s
MOT RS à 0.00 {0.01 W} 150.00 Motor stator resistance
à Depends on C0086
l Change of C0086 resets
value to the assigned Lenze
setting
C0085
s
MOT LS à 0.00 {0.01} 655.35 Motor leakage inductance
à Depends on C0086
l Change of C0086 resets
value to the assigned Lenze
setting
C0086
s
MOT TYPE à See motor selection list Selection of motor type
à Depending on the controller
used
l Change of C0086 resets
C0006, C0022, C0070,
C0071, C0075, C0076,
C0081, C0084, C0085,
C0087, C0088, C0089,
C0090, C0091 to the
assigned Lenze setting
Controller Lenze
setting Motor type
assigned Lenze motor type
EVS9321 110 MDSKS56−23−150 MDSKSXX056−23, f
N
: 150Hz
EVS9322 111 MDSKS56−33−150 MDSKSXX056−33, f
N
: 150Hz
EVS9323 112 MDSKS71−13−150 MDSKSXX071−13, f
N
: 150Hz
EVS9324 116 MDSKS71−33−150 MDSKSXX071−33, f
N
: 150Hz
EVS9325 15 MDFKA80−120 MDFKAXX080−22, f
N
: 120Hz
EVS9326 19 MDFKA90−120 MDFKAXX090−22, f
N
: 120Hz
EVS9327 23 MDFKA100−120 MDFKAXX100−22, f
N
: 120Hz
EVS9328 27 MDFKA112−120 MDFKAXX112−22, f
N
: 120Hz
EVS9329 225 30kW−ASM−50 —
EVS9330 227 45kW−ASM−50 —
EVS9331 228 55kW−ASM−50 —
EVS9332 229 75kW−ASM−50 —
C0087
s
MOT SPEED à 300 {1 rpm} 16000 Rated motor speed
à Depends on C0086
l Change of C0086 resets
value to the assigned Lenze
setting
