Configuration
Basic configurations
8
8.5
l
8.5−73 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1560 ARITPH6
FUNCTION
1 0
1
2
3
13
14
15
21
22 OUT = IN1
OUT = IN1 + IN2
OUT = IN1 − IN2
OUT = IN1 × IN2 / 2
30
OUT = IN1 × IN2
OUT = IN1 / IN2
OUT = IN1 % IN2
OUT = IN1 + IN2 (no limit)
OUT = IN1 − IN2 (no limit)
ARITPH6
Arithmetic function selection See system
manual
(extension)
C1561
s
1000 ® Selection list 3 ARITPH6
Configuration of input signals
1 ARITPH6−IN1 1000 FIXED0INC
2 ARITPH6−IN2 1000 FIXED0INC
C1562 g −2147483647 {1} 2147483647 ARITPH6
Display of input signals
1 ARITPH6−IN1
2 ARITPH6−IN2
C1570
s
® selection list 2 CONVDA1
Configuration of digital input
signals
See system
manual
(extension)
1 CONVDA1−B0 1000 FIXED0
2 CONVDA1−B1 1000 FIXED0
3 CONVDA1−B2 1000 FIXED0
4 CONVDA1−B3 1000 FIXED0
5 CONVDA1−B4 1000 FIXED0
6 CONVDA1−B5 1000 FIXED0
7 CONVDA1−B6 1000 FIXED0
8 CONVDA1−B7 1000 FIXED0
9 CONVDA1−B8 1000 FIXED0
10 CONVDA1−B9 1000 FIXED0
11 CONVDA1−B10 1000 FIXED0
12 CONVDA1−B11 1000 FIXED0
13 CONVDA1−B12 1000 FIXED0
14 CONVDA1−B13 1000 FIXED0
15 CONVDA1−B14 1000 FIXED0
16 CONVDA1−
SIGN
1000 FIXED0
C1571 RESULT g 0 {1 hex} 65536 CONVDA1
Display of the result
