Configuration
Basic configurations
8
8.5
l
8.5−5 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0050 MCTRL−NSET2 g −100.00 {0.01 %} 100.00 MCTRL
n
soll
at speed controller input
See system
manual
(extension)
C0051 MCTRL−NACT g −30000 {1 rpm} 30000 Actual speed value
C0052 MCTRL−UMOT g 0 {1 V} 800 Motor voltage
C0053 UG−VOLTAGE g 0 {1 V} 900 DC−bus voltage
C0054 IMOT g 0.0 {0.1 A} 300.0 Current motor current I
mot
MCTRL function block
l MCTRL−IACT = 100 % = C002
2
See system
manual
(extension)
C0056 MCTRL−MSET2 g −100.00 {0.01 %} 100.00 MCTRL−MSET2 (Mset)
Torque setpoint (n−controller
output)
See system
manual
(extension)
C0057 MAX TORQUE g 0 {1 Nm} 400 Max. torque
Max. possible torque of the
drive configuration
l Depending on C0022, C0086
C0058 ROTOR DIFF −90.0 −180.0 {0.1°} 179.9 Rotor displacement angle of
motor (offset angle)
Zero phase of the rotor for
synchronous motors (C0095).
If a resolver is selected in C0025
or C0490, C0058 is set to −90°.
l Lenze motor with resolver:
C0058 = (−)90°
l Lenze motor with Hiperface
absolute value encoder:
C0058 = 0°
C0059 MOT POLE NO. g 1 {1} 50 Number of motor pole pairs
C0060 ROTOR POS g 0 {1} 2047 Motor rotor position
1 revolution = 2048 inc
C0061 HEATSINK
TEMP
g 0 {1 °C} 100 Heatsink temperature See system
manual
(extension)
C0063 MOT TEMP g 0 {1 °C} 200 Motor temperature
C0064 UTILISATION g 0 {1 %} 150 Device utilisation Ixt
Utilisation of the last 180 s
C0064 >100 % releases trip OC5
Trip reset is only possible if
C0064 < 95 %
C0066 MOTOR LOAD g 0 {1 %} 150 I 2 × t utilisation of the motor
C0067 ACT TRIP g All fault messages à selection list 10 TRIP error message
Current fault message
C0070 VP SPEED CTRL à 0.0 {0.5} 255.0 V
pn
speed controller
à Depends on C0086
l Change of C0086 resets
value to the assigned
default setting
C0071 TN SPEED CTRL à 1.0 {0.5 ms} 600.0 T
nn
speed controller
>512 ms: Switched off
à Depends on C0086
l Change of C0086 resets
value to the assigned
default setting
C0072 TD SPEED−CTRL 0.0 0.0 {0.1 ms} 32.0 T
dn
speed controller
C0075 VP CURR−CTRL 0.35 0.00 {0.01} 15.99 V
pi
current controller
l Depends on C0086
l Change of C0086 resets
value to the assigned Lenze
setting
