Configuration, Basic configurations – Lenze EVS9332xP User Manual
Page 326
Configuration
Basic configurations
8.5
l
8.5−60
EDSVS9332P EN 5.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C1302
0.01
{0.01 %vmax}
100.00 POS
Input VTVEL speeds
See system
manual
(extension)
1 VTVEL−VALUE
10.00
2 VTVEL−VALUE
20.00
... ...
...
10 VTVEL−VALUE
100.00
... ...
...
30 VTVEL−VALUE
100.00
C1303
0.01
{0.01 %amax}
100.00 POS
Input of VTACC
accelerations/decelerations
See system
manual
(extension)
1 VTACC−VALUE
10.00
2 VTACC−VALUE
20.00
... ...
...
10 VTACC−VALUE
100.00
... ...
...
30 VTACC−VALUE
100.00
C1304
1
{1 pcs}
65535 POS
Input VTPCS piece numbers
See system
manual
(extension)
1 VTPCS−VALUE
1
... ...
...
30 VTPCS−VALUE
30
C1305
0
{0.001
s}
65535.000 POS
Input VTTIME waiting times
See system
manual
(extension)
1 VTTIME−VALUE
1.000
... ...
...
30 VTTIME−VALUE 30.000
C1311
0
No positioning/special function
POS
Program set mode
See system
manual
(extension)
1 PS MODE
0
1
Absolute PS
2 PS MODE
0
2
Relative PS
3 PS MODE
0
3
Homing
4 PS MODE
0
4
Set home position
5 PS MODE
0
5
Set position value to target position
(C1312)
6 PS MODE
0
6
Absolute PS, TP positioning with E01
7 PS MODE
0
7
Absolute PS, TP positioning with E02
... ...
...
8
Absolute PS, TP positioning with E03
25 PS MODE
0
9
Absolute PS, TP positioning with E04
25 PS MODE
0
11
Relative PS, TP positioning with E01
26 PS MODE
0
12
Relative PS, TP positioning with E02
27 PS MODE
0
13
Relative PS, TP positioning with E03
28 PS MODE
0
14
Relative PS, TP positioning with E04
29 PS MODE
0
16
Acceptance of home position (C1227)
28 PS MODE
0
30
Stand−by operation, cancel with
STDBY−STP
29 PS MODE
0
31
Stand−by operation, abort with TP E01
(+residual path)
30 PS MODE
0
32
Stand−by operation, abort with TP E02
(+residual path)
31 PS MODE
0
33
Stand−by operation, abort with TP E03
(+residual path)
32 PS MODE
0
34
Stand−by operation, abort with TP E04
(+residual path)
