Configuration
Basic configurations
8.5
l
8.5−32
EDSVS9332P EN 5.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C0732
s
® Selection list 1 OSC
Configuration of analog input
signals
See system
manual
(extension)
1 OSC
CHANNEL1
1000
FIXED0%
2 OSC
CHANNEL2
1000
FIXED0%
3 OSC
CHANNEL3
1000
FIXED0%
4 OSC
CHANNEL4
1000
FIXED0%
C0733
® selection list 2 OSC
Trigger input
1 OSC−TRIG INP
1000
FIXED0
C0734 TRIG−SOURCE
1
0
1
2
3
4
Digital trigger input
Measuring channel 1
Measuring channel 2
Measuring channel 3
Measuring channel 4
OSC
Selection of trigger source
See system
manual
(extension)
C0735 TRIGGER−LEVEL
0
−32767
{1}
32767 OSC
Setting of trigger level for
channels 1 ... 4
C0736 TRIGGER−SLOP
E
0
0
1
LOW/HIGH edge
HIGH/LOW edge
OSC
Selection of the trigger edge
C0737 TRIGGER−
DELAY
0.0
−100.0
{0.1 %}
999.9 OSC
Setting of pre− and
post−triggering
C0738 PROBE PERIOD
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
1 ms
2 ms
5 ms
10 ms
20 ms
50 ms
100 ms
200 ms
500 ms
1 s
2 s
5 s
10 s
20 s
50 s
1 min
2 min
5 min
10 min
OSC
Selection of the sampling
period
See system
manual
(extension)
C0739 NUMBER OF
CHANNELS
4
1
{1}
4 OSC
Number of channels to be
measured
See system
manual
(extension)
C0740 DATA READ
OSC
1
0
0
{1}
65535 Define the starting point for
reading the data memory. This
enables a selective access to a
memory block
2
0
0
1
Inhibit "Read data"
Enable "Read data"
Inhibit "Read memory"
