Lenze EVS9332xP - Manual (Page 300)

Configuration
Basic configurations
8
8.5
l
8.5−34 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0756 DFRFG1−
OFFSET
0 −1 . 10 9 {1 inc} 1 . 10 9 DFRFG1
Offset See system
manual
(extension)
C0757 DFRFG1−
FUNCTION
0 0
1 No TP start
With TP start DFRFG1
Function selection
C0758
s
DFRFG1−IN 1000 FIXEDPHI−0 ® Selection list 4 DFRFG1
Configuration of input signal
C0759
s
DFRFG1−QSP 1000 FIXED0 ® selection list 2 DFRFG1
Configuraton of digital input
signal
C0760
s
DFRFG1−STOP 1000 FIXED0 ® selection list 2 DFRFG1−STOP
Configuraton of digital input
signal
"Ramp function generator
stop"
C0761
s
DFRFG1−RESET 1000 FIXED0 ® selection list 2 DFRFG1
Configuraton of digital input
signal
Reset integrators
C0764 g DFRFG1
Display of digital input signals
1 DFRFG1−QSP
2 DFRFG1−STOP
3 DFRFG1−RESET
C0765 DFRFG1−IN g −32767 {1 rpm} 32767 DFRFG1
Display of input signal
C0766 DFRFG1−SPEED
DIR
1 1
2
3 Direction of rotation cw/ccw
CW rotation (to the right)
CCW rotation (to the left) DFRFG1
Selection of the direction of
rotation
C0770
s
FLIP1−D 1000 FIXED0 ® selection list 2 FLIP1
Data input
Configuraton of digital input
signal
See system
manual
(extension)
C0771
s
FLIP1−CLK 1000 FIXED0 ® selection list 2 FLIP1
Configuration of clock input
signal
C0772
s
FLIP1−CLR 1000 FIXED0 ® selection list 2 FLIP1
Configuration of reset input
signal
C0773 g FLIP1
Display of digital input signals
1 FLIP1−D
2 FLIP1−CLK
3 FLIP1−CLR
C0775
s
FLIP2−D 1000 FIXED0 ® selection list 2 FLIP2
Data input
Configuraton of digital input
signal
See system
manual
(extension)
C0776
s
FLIP2−CLK 1000 FIXED0 ® selection list 2 FLIP2
Configuration of clock input
signal
C0777
s
FLIP2−CLR 1000 FIXED0 ® selection list 2 FLIP2
Configuration of reset input
signal
C0778 g FLIP2
Display of digital input signals
1 FLIP2−D
2 FLIP2−CLK
3 FLIP2−CLR
