Lenze EVS9332xP - Manual (Page 281)

Configuration
Basic configurations
8
8.5
l
8.5−15 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0325 VP2 ADAPT 1.0 0.1 {0.1} 500.0 PCTRL
Process controller adaption
gain V
p2
See system
manual
(extension)
C0326 VP3 ADAPT 1.0 0.1 {0.1} 500.0 PCTRL
Process controller adaption
gain V
p3
See system
manual
(extension)
C0327 SET2 ADAPT 100.00 0.00 {0.01 %} 100.00 PCTRL
Set speed threshold nset2 of
the process controller
adaptation (condition:
C0327 > C0328)
See system
manual
(extension)
C0328 SET1 ADAPT 0.00 0.00 {0.01 %} 100.00 PCTRL
Setpoint speed threshold of the
process controller adaptation
l Condition: C0328 < C0327
See system
manual
(extension)
C0329 ADAPT
ON/OFF
0 0
1
2
3 No process controller adaptation
Externally via input
Adaptation via setpoint
Adaptation via control difference PCTRL
Activate process controller
adaption See system
manual
(extension)
C0332 PCTRL TIR 0.000 0.000 {0.001
s}
999.900 PCTRL
Acceleration time T
ir
(relating to setpoint change
0...100 %)
See system
manual
(extension)
C0333 PCTRL TIF 0.000 0.000 {0.001
s}
999.900 PCTRL
Deceleration time T
if
(relating to setpoint change
0...100 %)
See system
manual
(extension)
C0336 ACT VP g 0.0 {0.1} 500.0 PCTRL
Current gain V
p
See system
manual
(extension)
C0337 BI/UNIPOLAR 0 0
1 Bipolar
Unipolar PCTRL
Bipolar/unipolar process
controller range See system
manual
(extension)
C0338 ARIT1 FUNCT 1 0
1
2
3
4
5 OUT = IN1
OUT = IN1 + IN2
OUT = IN1 − IN2
OUT = IN1 × IN2
OUT = IN1 / IN2
OUT = IN1/(100% − IN2) ARIT1
Function selection See system
manual
(extension)
C0339
s
® Selection list 1 ARIT1
Configuration of analog input
signals
See system
manual
(extension)
1 ARIT1−IN1 1000 FIXED0%
2 ARIT1−IN2 1000 FIXED0%
C0340 g ARIT1
Display of analog input signals See system
manual
(extension)
1 (C0339/1)
2 (C0339/2)
C0350 CAN ADDRESS 1 1 {1} 63 CAN
System bus node address
l Change becomes effective
after ˜reset node˜ command
See system
manual
(extension)
C0351 CAN BAUD
RATE
0 0
1
2
3
4 500 kbps
250 kbps
125 kbps
50 kbps
1000 kbit/s CAN
System bus baud rate
l Change becomes effective
after ˜reset node˜ command
See system
manual
(extension)
