Configuration
Basic configurations
8
8.5
l
8.5−48 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1103
g
−32768 {1} 32768 FCNT1
Display of analog input signals
See system
manual
(extension)
1 FCNT1−LD−VAL
2 FCNT1−CMP−V
AL
C1104
g FCNT1
Display of digital input signals
1 FCNT1−CLKUP
2 FCNT1−
CLKDWN
3 FCNT1−LOAD
C1105 FCNT2−
FUNCTION
1 FCNT2
Function selection See system
manual
(extension)
1 Return If |counter
content|
³ |FCNT2−CMP−Val|,
FCNT2−EQUAL is set to HIGH for
1 ms
2 Hold if >= If |counter
content|
³ |FCNT2−CMP−Val|,
the counter stops
3 Hold if = If |counter
content| = |FCNT2−CMP−Val|,
the counter stops
C1106
s
® Selection list 1 FCNT2
Configuration of analog input
signals
See system
manual
(extension)
1 FCNT2−LD−VAL 1000 FIXED0%
2 FCNT2−CMP−V
AL
1000 FIXED0%
C1107
s
® selection list 2 FCNT2
Configuration of digital input
signals
1 FCNT2−CLKUP 1000 FIXED0
2 FCNT2−
CLKDWN
1000 FIXED0
3 FCNT2−LOAD 1000 FIXED0
C1108 g −32768 {1} 32768 FCNT2
Display of analog input signals
See system
manual
(extension)
1 FCNT2−LD−VAL
2 FCNT2−CMP−V
AL
C1109 g FCNT2
Display of digital input signals
1 FCNT2−CLKUP
2 FCNT2−
CLKDWN
3 FCNT2−LOAD
C1110 FCNT3−
FUNCTION
1 FCNT3
Function selection See system
manual
(extension)
1 Return If |counter
content|
³ |FCNT3−CMP−Val|,
FCNT3−EQUAL is set to HIGH for
1 ms
2 Hold if >= If |counter
content|
³ |FCNT3−CMP−Val|,
the counter stops
3 Hold if = If |counter
content| = |FCNT3−CMP−Val|,
the counter stops
