Configuration
Basic configurations
8.5
l
8.5−53
EDSVS9332P EN 5.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C1184 M−ID MAX
100
10
{1 %}
100 Control parameter
identification
l
Selection of the torque
l
100 % = M
max
C1185 M RISETIME
100
10
{1 ms}
10000 Control parameter
identification
l
Selection of the torque rise
time
C1186 OPTIMISE ID
0
0
1
Optimum control
Fault
Control parameter
identification
l
Optimisation of the control
parameter identification
C1187 INERTIA
0.0
0.0
{0.1 kg*cm
2
}
214000.
0
Control parameter
identification
Plant parameters
l
Inertia
C1188 FRICTION
0
0
{1 %}
100 Control parameter
identification
Plant parameters
l
Part of friction load
(proportional to speed)
C1190 MOTOR PTC
SELECTION
0
Temperature characteristic for
PTC thermistors
Selection of the characteristic
for PTC thermistors at X7 or X8
for detecting the motor
temperature
0
Standard
Characteristic for PTC
thermistors in Lenze motors
1
Characteristic
Characteristic for
application−specific PTC
thermistors
C1191 CHAR.:
TEMPERATURE
1
0
{1 °C}
255 Temperature range for PTC
thermistors
Define temperature points on
the characteristic for PTC
thermistors
1 CHAR.: TEMP 1
100
Temperature point 1
2 CHAR.: TEMP 2
150
Temperature point 2
C1192 CHAR.:
RESISTANCE 1
0
{1
W}
3000 Resistance range for PTC
thermistors
Define resistance points on the
characteristic for PTC
thermistors
1 CHAR.: OHM 1
1670
Resistance point 1
2 CHAR.: OHM 2
2225
Resistance point 2
C1195
s
AIF−OUT.D2
1000
FIXED0INC
® Selection list 3 AIF−OUT
Configuration of phase input
signal
See system
manual
(extension)
C1196 AIF−OUT.D2
g
−2147483647
{1}
2147483647 AIF−OUT
Display of input signal
C1197 AIF−IN.D2
g
AIF−IN
Display of input signal
See system
manual
(extension)
C1202 RATIO NUM.
1
1
{1}
65535 Gearbox factor numerator
See system
manual
(extension)
i + C1202
C1203 +
n
motor
n
gearbox_output
C1203 RATIO DENUM.
1
1
{1}
65535
Gearbox factor denominator
