Lenze EVS9332xP - Manual (Page 315)

Configuration
Basic configurations
8
8.5
l
8.5−49 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1111
s
® Selection list 1 FCNT3
Configuration of analog input
signals
See system
manual
(extension)
1 FCNT3−LD−VAL 1000 FIXED0%
2 FCNT3−CMP−V
AL
1000 FIXED0%
C1112
s
® selection list 2 FCNT3
Configuration of digital input
signals
1 FCNT3−CLKUP 1000 FIXED0
2 FCNT3−
CLKDWN
1000 FIXED0
3 FCNT3−LOAD 1000 FIXED0
C1113 g −32768 {1} 32768 FCNT3
Display of analog input signals
See system
manual
(extension)
1 FCNT3−LD−VAL
2 FCNT3−CMP−V
AL
C1114 g FCNT3
Display of digital input signals
1 FCNT3−CLKUP
2 FCNT3−
CLKDWN
3 FCNT3−LOAD
C1120 SYNC MODE 2 0
1
2 Sync switched off
CAN Sync activated
Terminal Sync activated SYNC1
Function See system
manual
(extension)
C1121
s
0 {1 ms} 13 SYNC1
The interpolation is restarted
with every sync signal.
1 SYNC CYCLE 2 Definition of the cycle time of
the sync signals (in the slave);
only for system bus
2 INTERPOL.
CYCL
2 Definition of the interpolation
time between the sync signals
(in the slave), only for terminal
C1122 SYNC TIME 0.460 0.000 {0.001
ms}
10.000 SYNC1
Phase shift between CAN Sync
and internal control program
cycle
l Only for system bus
l Depending on the baud rate
and bus load
See system
manual
(extension)
C1123 −0.450 {0.001
ms}
0.450 SYNC1 See system
manual
(extension)
1 PHASESHIFT 0.000 Phase shift between Terminal
Sync and internal control
program cycle
l Only for terminal sync
2 SYNC
WINDOW 0.200 Synchronisation window for
synchronisation edge of the
Terminal Sync (LOW−HIGH
edge)
l Only for terminal sync
l When the Sync signal is in
the window, SYNCx−STAT
switches to HIGH
