Configuration
Basic configurations
8
8.5
l
8.5−28 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0610
s
® Selection list
1
ADD1
Configuration of analog input
signals See system
manual
(extension)
1 ADD1−IN1 1000 FIXED0%
2 ADD1−IN2 1000 FIXED0%
3 ADD1−IN3 1000 FIXED0%
C0611 g −199.99 {0.01 %} 199.99 ADD1
Display of analog input signals
1 ADD1−IN1
2 ADD1−IN2
3 ADD1−IN3
C0620 DB1 GAIN 1.00 −10.00 {0.01} 10.00 DB1
Gain
See system
manual
(extension)
C0621 DB1 VALUE 1.00 0.00 {0.01 %} 100.00 DB1
Dead band
C0622
s
DB1−IN 1000 FIXED0% ® Selection list 1 DB1
Configuration − analog input
signal
C0623 DB1−IN g −199.99 {0.01 %} 199.99 DB1
Display of analog input signal
C0630 MAX LIMIT 100.00 −199.99 {0.01 %} 199.99 LIM1
Upper limit of the limiter
See system
manual
(extension)
C0631 MIN LIMIT −100.0 −199.99 {0.01 %} 199.99 LIM1
Lower limit of the limiter
C0632
s
LIM1−IN 1000 FIXED0% ® Selection list 1 LIM1
Configuration − analog input
signal
C0633 LIM1−IN g −199.99 {0.01 %} 199.99 LIM1
Display of analog input signal
C0640 PT1−1−DELAY T 20.00 0.01 {0.01 s} 50.00 PT1−1
Setting of the time constant
See system
manual
(extension)
C0641
s
PT1−1−IN 1000 FIXED0% à selection list 1 PT1−1
Configuration − analog input
signal
C0642 PT1−1−IN g −199.99 {0.01 %} 199.99 PT1−1
Display of analog input signal
C0650 DT1−1−GAIN 1.000 −320.00 {0.01} 320.00 DT1−1
Gain
See system
manual
(extension)
C0651 DT1−1−DELAY T 1.000 0.005 {0.001
s}
5.000 DT1−1
Time constant
C0652
s
DT1−1−IN 1000 FIXED0% ® Selection list 1 DT1−1
Configuration − analog input
signal
C0653 DT1−1−
SENSIBILITY
1 1
2
3
4
5
6
7 15 bits
14 bits
13 bits
12 bits
11 bits
10 bits
9 bits DT1−1
Sensitivity
C0654 DT1−1−IN g −199.99 {0.01 %} 199.99 DT1−1
Display of analog input signal
