Commissioning
Important notes
6
6.1
l
6.1−1 EDSVS9332P EN 5.0−07/2013
6.1 Important notes
(
Stop!
For applications with active loads (e.g. hoists), you must set
C0172 = 0 (OV reduce: threshold for activation of brake torque
reduction before OV message) so that an overvoltage message
(OV) can be generated.
ƒ As long as the overvoltage message (OV) is active, pulse inhibit
is set and the drive operates in zero−torque mode.
ƒ The controller inhibit is also evaluated by the holding brake
(BRK)" function block.
}
Danger!
Do not change any settings on the controller which are not
described in this chapter.
Carry out the commissioning systematically:
1. Carry out basic settings on the controller.
2. Carry out functional test of the manual control.
3. Enter travel profile parameters.
4. Reference the positioning application.
5. Control drive
Use a PC with the »Global Drive Control« (GDC) PC software for
commissioning. The full functionality of the servo cam profiler can only be
obtained through GDC
.
ƒ Possible communication paths between GDC and controller including
adapters and connection cables required:
Controller Connection PC
Interface PC adapter Interface
Integrated system
bus or
CANopen
communication
module
EMF2175IB System bus cable
(supplied with the
system bus
adapters) System bus adapter
EMF2173IB Parallel (printer
interface)
System bus adapter
EMF2177IB USB
Communication
module LECOM−A/B
EMF2102IBCV001 Serial cable
EWL0020
EWL0021 A standard RS232 / RS485
converter and an RS485
connection cable are required
for LECOM−B. Serial (RS232)
Communication
module LECOM−LI
EMF2102IBCV003 Optical fibre
EWZ0006
EWZ0007 Optical fibre adapter
EMF2125IB
EMF2126IB
Active loads
Commissioning sequence
»Global Drive Control« (GDC)
